Patch cable - RJ-45 (M) to RJ-45 (M) - 12 m - 5.6 mm - S/FTP - CAT 5/5e/6/6a/8 - IEEE 802.3bt/IEEE 802.3ba - halogen-free, snagless - white | NLWH-12M-CAT8-PATCH
NLWH-12M-CAT8-PATCH
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
- Enhanced connectivity
Experience seamless network performance with the 12m White CAT8 Ethernet Cable, designed for high-speed data transmission up to 40 Gbps. Its S/FTP technology ensures minimal interference, making it ideal for demanding network environments. - Durable design
Built with a Low Smoke Zero Halogen (LSZH) jacket and featuring snagless, halogen-free construction, this cable is designed for both safety and longevity. The pure bare copper conductors and strain relief add to its durability, ensuring a stable connection. - High performance
Equipped with gold-plated connectors and aluminum mylar foil with braid shielding, the cable offers exceptional EMI protection and 100W PoE++ support. Its compliance with IEEE standards and TIA/EIA T568B wiring scheme validates its quality and reliability.
Special Fetures
- Supports data transmission speeds up to 40 Gbps for efficient networking
- Features 100W PoE++ support, enabling power and data transmission over a single cable
- Constructed with pure bare copper conductors for superior conductivity
- Flame-retardant and EMI protected for enhanced safety and signal quality
- Snagless design and strain relief for increased durability
Product Specification
| Network Cable Type | Patch cable - CAT 5/5e/6/6a/8 - IEEE 802.3bt/IEEE 802.3ba |
| Technology | S/FTP |
| Wiring Scheme | T568B |
| Shielding Material | Aluminum mylar foil with braid |
| Jacket Material | Low Smoke Zero Halogen (LSZH) |
| American Wire Gauge (AWG) | 26 |
| Wires per Cable | 8 wires |
| Pairs per Cable | 4 pairs |
| Plated Connector | Gold |
| Features | Halogen-free, snagless, flame retardant, strain relief, test fluke pass, pure bare copper conductors, up to 40 Gbps, EMI protection, 100W PoE++ support |
| Length | 12 m |
| Diameter | 5.6 mm |
| Colour | White |
| Connectivity | |
| Connector | RJ-45 - male |
| Connector (Second End) | RJ-45 - male |
| Miscellaneous | |
| Compliant Standards | WEEE, TIA/EIA T568B - up to 2000 MHz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 22 cm |
| Shipping Depth | 31 cm |
| Shipping Height | 4.5 cm |
| Shipping Weight | 500 g |
| Manufacturer Warranty | |
| Service & Support | Limited lifetime warranty |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
