Server - rack-mountable 2U - 2-way - 1 x Xeon Silver 4309Y / up to 3.6 GHz - RAM 64 GB - SATA/SAS - hot-swap 2.5" bay(s) - SSD 2 x 480 GB - Gigabit Ethernet - no OS - monitor: none | P77170-425
Server - rack-mountable 2U - 2-way - 1 x Xeon Silver 4309Y / up to 3.6 GHz - RAM 64 GB - SATA/SAS - hot-swap 2.5" bay(s) - SSD 2 x 480 GB - Gigabit Ethernet - no OS - monitor: none | P77170-425
€4697.39 inc. VAT
P77170-425
CPU TypeIntel Xeon
Memory Size64GB
Product CodeCL56433
EAN Code0190017767475
ManufacturerHewlett Packard
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
- Reliable processing power
Powered by an Intel Xeon Silver processor with 8 cores, the system is capable of running heavy applications smoothly and can be scaled by adding an additional processor. - Efficient memory management
With support for HPE Persistent Memory and 64 GB of DDR4 SDRAM, it operates quickly while maintaining efficient memory usage, alongside 30 available slots for future upgrades. - Flexible storage options
The server features 8 hot-swap bays for 2.5" drives, allowing for swift integration and replacement of storage without downtime, suitable for both SATA and SAS drives. - Enhanced remote management
Integrated Lights-Out 5 offers remote management capabilities, enabling users to monitor and manage server tasks from anywhere, streamlining IT operations. - Robust environmental compliance
This server complies with stringent environmental standards, including ENERGY STAR certification, ensuring sustainable energy use and a commitment to reducing the environmental footprint.
Special Fetures
- Hot-swap bays support easy drive replacements
- Upgradable with options to add more processors
- 80 PLUS Titanium certified power supply for energy efficiency
- Integrated remote management for streamlined server control
- Robust environmental standards for operational reliability
Product Specification
| Type | Server |
| Product Form Factor | Rack-mountable - 2U |
| Embedded Security | Trusted Platform Module (TPM) Security Chip |
| Server Scalability | 2-way |
| Hot-Swap Bays Qty | 8 |
| Localisation | Region: Europe |
| Processor / Chipset | |
| CPU | Intel Xeon Silver 4309Y |
| Clock Speed | 2.8 GHz |
| Max Turbo Speed | 3.6 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| Chipset Type | Intel C621A |
| Cache Memory | |
| Installed Size | L3 Cache - 12 MB |
| Cache Per Processor | 12 MB |
| RAM | |
| Installed Size | 64 GB (installed) / 2 TB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 1600 MHz |
| Rated Memory Speed | 1600 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 32 (Total) / 30 (empty) |
| Features | Registered, HP SmartMemory, 8-channel memory architecture, slots 17 - 32 are available in two-processor configuration only |
| Configuration Features | 2 x 32 GB |
| RAM Supported | 8 TB Load-Reduced <br /> 2 TB registered <br /> 8 TB - HPE Persistent Memory - Optane DC Persistent |
| Hard Drive | |
| Type | SSD |
| Capacity | 2 x 480 GB |
| Interface Type | SATA |
| Storage Controller | |
| Type | 1 x SAS/NVMe |
| Controller Interface Type | SATA 6Gb/s / SAS 4.0 / PCI Express |
| Storage Controller Name | HPE SR416i-a Gen10 |
| Channel Qty | 16 |
| Buffer Size | 4 GB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Video Memory | 16 MB |
| Video Interfaces | VGA |
| Networking | |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | Broadcom BCM5719 |
| Data Link Protocol | Gigabit Ethernet, Ethernet, Fast Ethernet |
| Remote Management Controller | Integrated Lights-Out 5 |
| Expansion / Connectivity | |
| Bays | 8 (total) / 6 (free) x hot-swap 2.5" SFF |
| Slots | 1 (total) / 1 (free) x PCIe 4.0 x16 - full-length, full-height <br /> 1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, full-height (x8 mode) <br /> 1 (total) / 1 (free) x PCIe 4.0 x16 - full-length, full-height (x8 mode) |
| Interfaces | 1 x HPE iLO - RJ-45 <br /> 1 x USB 3.0 <br /> 1 x HPE iLO (service port) <br /> 4 x LAN (Gigabit Ethernet) <br /> 1 x VGA |
| Miscellaneous | |
| Included Accessories | 6 maximum performance fans |
| Compliant Standards | AES, FIPS 140-2, WEEE, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, UEFI, ACPI 6.3, SMBIOS 3.2 |
| Power | |
| Device Type | Power supply - hot-plug |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 200-240 V |
| Power Provided | 800 Watt |
| 80 PLUS Certification | 80 PLUS Titanium |
| Operating System / Software | |
| OS Provided | No operating system |
| Software | HPE iLO Standard with Intelligent Provisioning |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 4.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| Dimensions & Weight | |
| Width | 44.54 cm |
| Depth | 71 cm |
| Height | 8.75 cm |
| Environmental Parameters | |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 8 - 90% (non-condensing) |
