Product Features
- Small and flexible
The smaller size and external power supply of the MMC10G series allows them to be used almost anywhere. - VLAN support
The MMC10G series are compatible with long packets, enabling them to be used in modern networks. Media converters not supporting this feature discard these extra long packets, making them unsuitable for modern networks. - Traffic generator
The MMC10G series has a loopback function and traffic generator to help diagnose network connections.
Special Fetures
- Small and flexible
- VLAN support
- Traffic generator
Product Specification
| Device Type | Fibre media converter |
| Form Factor | External |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-X, 10GBase-X |
| Data Link Protocol | 10GbE |
| Data Transfer Rate | 10 Gbps |
| Status Indicators | Power, system, link/activity |
| Features | MissingLink, wall mountable, Energy Efficient Ethernet, 10 KB Jumbo Frame |
| Compliant Standards | IEEE 802.1Q |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 10GBase-X - SFP+ female <br /> 1 x Ethernet 10GBase-X - SFP+ female |
| Miscellaneous | |
| Compliant Standards | FCC Class A certified, VCCI, C-Tick, CISPR 22 Class A, UL 60950-1, EN 60950-1, EN 55022 Class A |
| TAA Compliant | Yes |
| Power | |
| Voltage Required | DC 12 V |
| Power Consumption Operational | 4 Watt |
| Dimensions & Weight | |
| Width | 5.6 cm |
| Depth | 10.16 cm |
| Height | 2.18 cm |
| Weight | 170 g |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Features - Allied Telesis - AT-MMC10GSP/SP-960
More Details
Product Code
CA05826
EAN Code
0767035217840
Manufacturer
Allied Telesis
