Allied Telesis AT FS710/5E / Switch / unmanaged / 5 x 10/100 / desktop, wall-mountable | AT-FS710/5E-60
Please sign in so that we can notify you about a reply
Allied Telesis AT FS710/5E / Switch / unmanaged / 5 x 10/100 / desktop, wall-mountable | AT-FS710/5E-60
Description
The FS710/5E unmanaged fast Ethernet switch is an economical and eco-friendly solution, with 5 x 10/100TX ports and an external PSU.
Product Specification
| Device Type | Switch - 5 ports - unmanaged |
| Enclosure Type | Desktop, wall-mountable |
| Subtype | Fast Ethernet |
| Ports | 5 x 10/100 |
| Performance | Switching capacity: 1 Gbps ¦ Throughput: 0.74 Mpps |
| MAC Address Table Size | 2K entries |
| Features | Flow control, auto-negotiation, Jumbo Frames support, fanless, 96KB packet buffer, Bridge protocol data unit (BPDU) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3az |
| Status Indicators | Power, link/activity |
| Interfaces | 5 x 100Base-TX RJ-45 |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50 - 60 Hz) |
| Power Consumption Operational | 1.7 Watt |
| Compliant Standards | FCC Class B certified, UL 60950-1, EN 60950-1, VCCI Class B, CSA 22.2 No. 60950-1, EN 55032 Class A, CISPR 32 Class B, EU RoHS, RCM Class B |
| Width | 13.1 cm |
| Depth | 10.1 cm |
| Height | 3 cm |
| Weight | 380 g |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Min Storage Temperature | -25 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 95% (non-condensing) |
Features - Allied Telesis - AT-FS710/5E-60
General
5-Port
More Details
Product Code
425A913
EAN Code
0767035211756
Manufacturer
Allied Telesis
