Allied Telesis Industrial Ethernet Media Converter AT-IMC200T/SC / Fibre media converter / 100Mb LAN / 10Base-T, 100Base-FX, 100Base-TX / RJ-45 / SC multi-mode / up to 2 km | AT-IMC200T/SC-980
AT-IMC200T/SC-980
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Specification
Device Type | Fibre media converter |
Form Factor | External |
Networking | Networking |
Connectivity Technology | Wired |
Cabling Type | 10Base-T, 100Base-FX, 100Base-TX |
Data Link Protocol | 100Mb LAN |
Data Transfer Rate | 100 Mbps |
Max Transfer Distance | 2 km |
Status Indicators | Link/activity |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | 1 x Ethernet 100Base-FX - SC multi-mode female x 2 ¦ 1 x Ethernet 100Base-TX - RJ-45 female |
Miscellaneous | Miscellaneous |
Compliant Standards | FCC Class A certified, VCCI, EN55024, ICES, EN61000-3-2, EN61000-3-3, EN 55032 |
Dimensions & Weight | Dimensions & Weight |
Width | 11.1 cm |
Depth | 9.6 cm |
Height | 3.5 cm |
Weight | 748 g |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | -40 °C |
Max Operating Temperature | 75 °C |
Humidity Range Operating | 5 - 90% (non-condensing) |
