APC Basic Rack PDU AP6020A / Power distribution unit (rack-mountable) / AC 100-240 V / input: IEC 60320 C20 / output connectors: 13 (IEC 60320 C13) / for P/N: SMC1000I-2UC, SMC1500I-2UC, SMC1500IC, SRT1000RMXLI, SRT1000RMXLI-NC, SRT5KRMXLW-HW | AP6020A
Description
The APC by Schneider Electric basic Rack PDU distributes power to the devices in the rack. The Rack PDU has thirteen C13 outlets.
Product Specification
| Device Type | Power distribution unit - rack-mountable |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power IEC 60320 C20 |
| Power Output Connectors Details | 13 x power IEC 60320 C13 |
| Output Voltage | AC 100-240 V + 6% / - 10% |
| Max Electric Current | 20 A |
| Compliant Standards | UL, VDE, RoHS 2011/65/EU |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Width | 4.36 cm |
| Depth | 9.29 cm |
| Height | 38.81 cm |
| Weight | 1.5 kg |
| Shipping Width | 21.03 cm |
| Shipping Depth | 7.59 cm |
| Shipping Height | 43.61 cm |
| Shipping Weight | 2 kg |
| Designed For | P/N: SMC1000I-2UC, SMC1500I-2UC, SMC1500IC, SRT1000RMXLI, SRT1000RMXLI-NC, SRT5KRMXLW-HW, SUA5000RMI5U, SURT1000XLI, SURT2000XLI, SYA8K8RMI |
Features - APC - AP6020A
More Details
Product Code
270B730
EAN Code
0731304327806
Manufacturer
APC
