ASUS 4G-AC68U / Wireless router / WWAN / 4-port switch / GigE / 802.11a/b/g/n/ac / Dual Band service not included | 90IG03R1-BM2000
ASUS 4G-AC68U / Wireless router / WWAN / 4-port switch / GigE / 802.11a/b/g/n/ac / Dual Band service not included | 90IG03R1-BM2000
Description
ASUS 4G-AC68U features the LTE Category 6 mobile broadband, which combines two cellular bands to give you internet download speeds of up to 300 Mbps - 2X faster than LTE Category 4, and 7X faster than 3G (HSPA+) - so you can share even the biggest files and stream 4K UHD video with ease. And with the super-fast 1900 Mbps 802.11ac Wi-Fi, you can enjoy wireless speeds that are up to 3X faster than 802.11n.ASUS AiRadar intelligently strengthens wireless connectivity using beam forming technology, high power amplification, and exclusive ASUS RF fine-tuning. This ensures extended coverage, dynamic data speed increases, and enhanced stability.Built into ASUS 4G-AC68U, the Intrusion Prevention System (IPS) in AiProtection provides multi-point protection for every connected device on your network and blocks all common internet-based attacks. Automated regular and time-sensitive AiProtection updates ensure that you always have the most up-to-date protection.
ASUS 4G-AC68U / Wireless router | 90IG03R1-BM2000
Special Features
- Fast Wi-Fi speeds - concurrent dual-band Wi-Fi delivers smooth streaming with 2.4 GHz speeds up to 600 Mbps and 5 GHz speeds up to 1300 Mbps
- Ultimate 4G speed - 4G LTE Category 6 technology lets you enjoy 7X-faster speeds than 3G mobile broadband
- Optimized Wi-Fi range - AiRadar beam forming and high-power antennas for better coverage
- Parental controls - monitor and restrict internet activity for any user
- Enterprise-grade security - ASUS AiProtection provides advanced protection for all devices connected to your home network
Product features
- Super-fast mobile broadband, super-fast Wi-Fi
ASUS 4G-AC68U features the LTE Category 6 mobile broadband, which combines two cellular bands to give you internet download speeds of up to 300 Mbps - 2X faster than LTE Category 4, and 7X faster than 3G (HSPA+) - so you can share even the biggest files and stream 4K UHD video with ease. And with the super-fast 1900 Mbps 802.11ac Wi-Fi, you can enjoy wireless speeds that are up to 3X faster than 802.11n. - Unbeatable Wi-Fi coverage
ASUS AiRadar intelligently strengthens wireless connectivity using beam forming technology, high power amplification, and exclusive ASUS RF fine-tuning. This ensures extended coverage, dynamic data speed increases, and enhanced stability. - Improved protection against attacks
Built into ASUS 4G-AC68U, the Intrusion Prevention System (IPS) in AiProtection provides multi-point protection for every connected device on your network and blocks all common internet-based attacks. Automated regular and time-sensitive AiProtection updates ensure that you always have the most up-to-date protection. - Detachable and upgradeable 4G LTE antennas
External mobile broadband antennas perform better than internal antennas. Indoors, the best 4G LTE reception is usually found near a window, but if this isn't practical you can easily add an antenna extension cable thanks to the detachable antennas with their standard SMA jack connectors. - 4G LTE and Gigabit Ethernet dual-WAN for interruption-free connections
In addition to its 4G LTE capability, 4G-AC68U has a dedicated Gigabit Ethernet WAN port that can be used as a backup wired internet connection that is activated when the 4G LTE connection fails (failover), and automatically switches back when service is restored (failback). This gives superb flexibility for business or home use - you need never be without an internet connection. - Easy 3-step Plug-n-Surf
It only takes three steps to get connected with 4G-AC68U. - Robust control and optimization with ASUSWRT
With the ASUSWRT dashboard UI, setup, monitor, and control network applications all in one intuitive area. On top of 30-second setup, multi-device detection, and flexible settings that make the most of your network performance, it's been upgraded with quick scanning of USB storage connected to routers to verify data integrity and drive health. Dual WAN enables having two connections/ISPs on one router, with load balance and failover mode for added stability and redundancy to ensure uninterrupted internet access. Do you game a lot, or spend most of your time streaming videos? Whatever your planned use is, the 4G-AC68U has Adaptive Quality of Service (QoS) that optimizes inbound and outbound bandwidth on both wired and wireless connections. Applications and tasks can be prioritized easily using drag-and-drop presets for gaming, media streaming, VoIP, web browsing and file transfers. It supports major consoles including PlayStation 3, PlayStation 4, PS4 Pro, PlayStation Vita, Wii U, 3DS and Xbox One. - VPN server and client for encrypted remote connection
With the virtual private network (VPN) server and VPN client, you can access your home network remotely or surf the internet with encryption, no need for paid VPN services or a dedicated VPN server. - Create your own personal cloud
ASUS AiCloud keeps you close to your data wherever and whenever you have an internet connection. It links your home network and online storage service, giving you access to your files using the AiCloud mobile app on your iOS, Android smartphones or via a personalized browser URL. You can share photos instantly to services like Facebook, Flickr or Dropbox directly from the AiCloud interface. Even better, AiCloud can be connected to another compatible router to expand your personal cloud even further.
Product Specification
Device Type | Wireless router - 4-port switch (integrated) |
Service Provider | Service not included |
Enclosure Type | Desktop |
Connectivity Technology | Wireless, wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Frequency Band | 2.4 GHz / 5 GHz |
Data Transfer Rate | 1900 Mbps |
Capacity | Guest networks: 6 |
Network / Transport Protocol | PPTP, L2TP, NTP, IPSec, PPPoE, DHCP, DDNS |
Routing Protocol | IGMPv2, IGMP, static IP routing, IGMPv3 |
Encryption Algorithm | MPPE, 128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise |
Wi-Fi AC Rating | AC1900 |
Features | DoS attack prevention, print server, IPv6 support, URL filtering, parental control, Access Point operational mode, MIMO technology, event log, Wi-Fi Protected Setup (WPS), IPSec passthrough, Multiple SSID support, static IP mode, DNS proxy, wireless bridge mode, reset button, IPv4 support, port triggering, Stateful Packet Inspection Firewall (SPIF), ASUS Universal repeater, Multicast Proxy support, VPN Server, ASUS AiCloud, Multicast Rate Setting support, Broadcom TurboQAM technology, PPTP passthrough, wireless extender mode, L2TP passthrough, ASUS AiProtection, port filtering, Roaming Assist technology, Adaptive QoS, VPN client, ASUS Router App, Airtime Fairness, Traffic Analyser |
Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac |
RAM | 256 MB |
Flash Memory | 128 MB |
Status Indicators | Power, WAN, LAN, wireless, USB, 3G, WPS, 4G |
Type | Wireless cellular modem |
Cellular Protocol | UMTS, HSPA+, LTE, FDD LTE, TDD LTE |
Max Transfer Rate | 300 Mbps |
Interfaces | WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB 3.0: 1 x 9 pin USB Type A |
Expansion Slots | 1 (total) / 1 (free) x SIM |
Aerial | External detachable and internal |
Antenna Qty | 5 |
Power Device | External power adapter |
Voltage Required | AC 120/230 V (50/60 Hz) |
Enclosure Colour | Black |
Cables Included | 1 x network cable |
OS Required | Linux, Microsoft Windows 2000, Microsoft Windows Millennium Edition, Apple MacOS X, Microsoft Windows XP, Apple MacOS X 10.1, Microsoft Windows Server 2003, Microsoft Windows 7, Apple MacOS X 10.4, Microsoft Windows Vista, Apple MacOS X 10.6, Microsoft Windows Server 2008, Apple MacOS X 10.5, Apple MacOS X 10.7 Lion, Windows 8, Apple MacOS X 10.8, Windows 8.1, Windows 10 |
Width | 24.7 cm |
Depth | 7.6 cm |
Height | 16.8 cm |
Weight | 795 g |
