ASUS ExpertCenter PN52 S9032MD / Mini PC / Ryzen 9 5900HX / 3.3 GHz / RAM 16 GB / SSD 1 TB / NVMe / Radeon Graphics / GigE, 2.5 GigE, Bluetooth 5.2, 802.11ax (Wi-Fi 6E) / WLAN: Bluetooth 5.2, 802.11a/b/g/n/ac/ax (Wi-Fi 6E) / no OS | 90MS02F1-M00100
Please sign in so that we can notify you about a reply
Product Features
- 4K resolution and quad display support
ASUS ExpertCenter PN52 can support up to four 4K displays via two HDMI ports, DisplayPort over USB-C or other user-configurable ports, without any limitation on the combination used. - Ultra-realistic 8K visuals
ASUS ExpertCenter PN52 delivers breathtaking 8K visuals at 30 frames per second via the configurable standard DisplayPort or DisplayPort over USB-C. Experience a level of detail that's 4x greater than 4K, or 16x that of traditional FHD output. - USB Power Delivery input
ASUS ExpertCenter PN52 can draw power from any USB Power Delivery-enabled display or device, eliminating the need for a separate power adapter to create a neater, uncluttered workspace. - Easy upgrades
An easy-access underside panel allows users replace and upgrade memory, storage and the wireless card. All that's required is a screwdriver. - Configurable port
ASUS ExpertCenter PN52 is well-equipped for a wide range of functions and can be used for digital signage, POS systems or intelligent vending machines. The configurable port can be specified with either HDMI, VGA, DisplayPort, or COM ports, as well as 2.5GBE LAN, for monitors or legacy devices such as barcode scanners or receipt printers. - Superfast 2.5 GBps networking
2.5GBE Ethernet provides superfast networking and data transfer speeds for efficient, productive multitasking. - Military-grade durability
ASUS ExpertCenter PN52 is subjected to rigorous MIL-STD-810H durability tests, enduring extreme temperatures and humidity, high altitude, plus drop and vibration tests to ensure it's fit to perform in the harshest conditions.
Special Features
- 4K resolution and quad display support
- Ultra-realistic 8K visuals
- USB Power Delivery input
- Easy upgrades
- Configurable port
- Superfast 2.5 GBps networking
- Military-grade durability
Product Specification
| Type | Personal computer |
| Product Form Factor | Mini PC |
| Embedded Security | Trusted Platform Module (TPM) Security Chip |
| Colour | Eco black |
| Processor / Chipset | Processor / Chipset |
| CPU | AMD Ryzen 9 5900HX |
| Clock Speed | 3.3 GHz |
| Max Turbo Speed | 4.6 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Cache Memory | Cache Memory |
| Installed Size | L3 Cache - 16 MB |
| Cache Per Processor | 16 MB |
| RAM | RAM |
| Installed Size | 16 GB |
| Technology | DDR4 SDRAM |
| Rated Memory Speed | 3200 MHz |
| Form Factor | SO-DIMM 260-pin |
| Hard Drive | Hard Drive |
| Type | SSD - M.2 |
| Capacity | 1 x 1 TB |
| Interface Type | PCI Express 3.0 |
| Features | NVM Express (NVMe) |
| Storage Controller | Storage Controller |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Optical Storage | Optical Storage |
| Type | No optical drive |
| Monitor | Monitor |
| Monitor Type | None. |
| Graphics Controller | Graphics Controller |
| Graphics Processor | AMD Radeon Graphics |
| Video Interfaces | HDMI, DisplayPort |
| Networking | Networking |
| Ethernet Controller | Realtek RTL8125B-CG |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E) |
| Features | Dual stream (2x2) |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x USB-C 3.2 Gen 2 ¦ 1 x USB 3.2 Gen 2 ¦ 4 x USB 3.2 Gen 1 ¦ 1 x USB-C 3.2 Gen 1 ¦ 1 x headphones/microphone ¦ 2 x HDMI ¦ DisplayPort 1.4 |
| Miscellaneous | Miscellaneous |
| Compliant Standards | UL, VCCI, C-Tick, BSMI, CB, CCC, FCC |
| Power | Power |
| Device Type | Power adapter |
| Power Provided | 120 Watt |
| Operating System / Software | Operating System / Software |
| OS Provided | No operating system |
| Environmental Standards | Environmental Standards |
| ENERGY STAR Certified | Yes |
| Dimensions & Weight | Dimensions & Weight |
| Width | 12 cm |
| Depth | 13 cm |
| Height | 5.8 cm |
| Weight | 1 kg |
Features - Asus - 90MS02F1-M00100
CPU Type
- AMD Ryzen
Capacity
1TB
More Details
Product Code
03:206819
EAN Code
4711081869863
Manufacturer
Asus
