ASUS Mini PC PN50 BBR343MD-CSM / Barebone / mini PC / 1 x Ryzen 3 4300U / 2.7 GHz / RAM 0 GB / Radeon Graphics / GigE / WLAN: Bluetooth 5.0, 802.11a/b/g/n/ac/ax | 90MR00E1-M00150
ASUS Mini PC PN50 BBR343MD-CSM / Barebone / mini PC / 1 x Ryzen 3 4300U / 2.7 GHz / RAM 0 GB / Radeon Graphics / GigE / WLAN: Bluetooth 5.0, 802.11a/b/g/n/ac/ax | 90MR00E1-M00150
Description
ASUS Mini PC PN50 is an ultracompact computer that delivers powerful performance for a wide variety of home and business applications. Mini PC PN50 is ready to take on demanding workloads, yet its diminutive size takes up minimal space on a desk and makes it suited for applications where traditional PCs won't fit - from digital signage to home-theater setups.
ASUS Mini PC PN50 BBR343MD-CSM / Barebone | 90MR00E1-M00150
Special Features
- 4K resolution and quad-display support
- Ready for any scenario
- Modern, space-saving design
- High-speed connectivity and legacy support
- HDMI CEC header and IR sensor
- Whole system cooling
- Reduce environmental impact while lowering operating costs
Product features
- 4K resolution and quad-display support
ASUS Mini PC PN50 supports up to four displays with 4K resolution through HDMI, DisplayPort over USB-C and user-configurable ports, without any limitation on the combination. - Ready for any scenario
ASUS Mini PC PN50 supports up to four video outputs, so it offers flexibility to handle all manner of multi-display setups. Moreover, you have the freedom to choose your own combination of ports, making PN50 is suitable for almost any conceivable display scenario. - Modern, space-saving design
With a modern design featuring sleek lines and a stylish, brushed finish, ASUS Mini PC PN50 easily blends into home, office and retail environments. - High-speed connectivity and legacy support
ASUS Mini PC PN50 provides comprehensive connectivity with multiple ports, including dual USB 3.2 Gen 2 Type-C ports with DisplayPort 1.4 support and a configurable port to support legacy devices, additional displays or multiple network connections. - HDMI CEC header and IR sensor
ASUS Mini PC PN50 supports HDMI CEC, allowing you to manage almost all your media devices, from audio and video playback to menu navigation, via a single remote control. - Whole system cooling
FAN will also adjust the speed according to the M.2 SSD temperature to achieve better heat dissipation (in the past, only the CPU temperature was monitored). - Reduce environmental impact while lowering operating costs
ASUS Mini PC PN50 has an energy-efficient design that reduces environmental impact while helping to lower operating costs for your business.
Product Specification
Type | PC barebone |
Product Form Factor | Mini PC |
Sensors | Infrared (IR) sensor |
Colour | Black |
CPU | AMD Ryzen 3 4300U / 2.7 GHz |
Max Turbo Speed | 3.7 GHz |
Number of Cores | Quad-Core |
CPU Qty | 1 |
Max CPU Qty | 1 |
Installed Size | 0 GB |
Technology | DDR4 SDRAM |
Type | No HDD |
Type | No optical drive |
Type | 4 in 1 card reader |
Monitor Type | None. |
Graphics Processor | AMD Radeon Graphics |
Video Interfaces | HDMI, DisplayPort |
Type | Two microphones |
Wireless LAN Supported | Yes |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6) |
Compliant Standards | Wi-Fi CERTIFIED 6 |
Bays | Internal 2.5" |
Slots | M.2 Card |
Interfaces | 1 x HDMI ¦ 1 x LAN (Gigabit Ethernet) ¦ 2 x DisplayPort/USB-C 3.1 Gen 2 (1 front, 1 rear) ¦ 1 x headphones/microphone (1 in front) ¦ 3 x USB 3.1 Gen 1 (1 front, 2 rear) ¦ 1 x DisplayPort |
Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
Security Slot Type | Kensington security slot |
Device Type | Power adapter |
Power Provided | 65 Watt |
OS Provided | No operating system |
Width | 11.5 cm |
Depth | 11.5 cm |
Height | 4.9 cm |
Weight | 700 g |
