ASUS P12R-M/10G-2T / Motherboard / micro ATX / LGA1200 Socket / C252 Chipset / USB 3.2 Gen 1, USB 3.2 Gen 2 / 2 x 10 Gigabit LAN / onboard graphics | 90SB0AC0-M0UAY0
Please sign in so that we can notify you about a reply
Special Features
- Ideal for remote office/branch office (ROBO) use and everyday business environments
- Powered by eight-core Intel Xeon E-2300-series processor with support for up to 95 W TDP
- Flexible expandability with six native SATA HDDs and two PCI Express 4.0 slots
- Dual Intel X710AT Gigabit Ethernet with teaming support
- One M.2 for up to 32 Gbps performance for faster OS booting
- HDMI 1.4 support for high-resolution display maintenance and monitoring
- Onboard ASUS ASMB10-iKVM with ASPEED AST2600 controller for out-of-band management
- Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
Product Specification
| Product Type | Motherboard - micro ATX |
| Chipset Type | Intel C252 |
| Processor Socket | LGA1200 Socket |
| Max Processors Qty | 1 |
| Compatible Processors | Pentium, Xeon E |
| Supported RAM | Supported RAM |
| Max Size | 128 GB |
| Technology | DDR4 |
| Bus Clock | 2666 MHz, 2933 MHz, 3200 MHz |
| Registered or Buffered | Unbuffered |
| Features | Dual channel memory architecture |
| Graphics | Graphics |
| Graphics Controller | ASPEED AST2600 |
| Dedicated Video Memory | 64 MB |
| LAN | LAN |
| Network Controller | Intel X710-AT2 |
| Network Interfaces | 2 x 10 Gigabit Ethernet |
| Expansion / Connectivity | Expansion / Connectivity |
| Expansion Slots | 1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 4.0 x16 ¦ 1 x PCIe 4.0 x8 (x4 mode) |
| Storage Interfaces | SATA-600 -connectors: 6 x 7pin Serial ATA ¦ PCIe -connectors: 1 x M.2 |
| Interfaces | 2 x LAN (10Gigabit Ethernet) ¦ 1 x management ¦ 1 x HDMI ¦ 1 x VGA ¦ 2 x USB 3.2 Gen 2 |
| Internal Interfaces | 2 x USB 2.0 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x serial - header |
| Power Connectors | 24-pin main power connector, 8-pin ATX12V connector |
| Miscellaneous | Miscellaneous |
| Included Accessories | I/O back cover, ASUS ASMB10-IKVM management card |
| Width | 24.4 cm |
| Depth | 24.4 cm |
| Weight | 760 g |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Weight | 1.3 kg |
Features - Asus - 90SB0AC0-M0UAY0
More Details
Product Code
04:390725
EAN Code
4711081419747
Manufacturer
Asus
