ASUS ROG MAXIMUS XII HERO (WI-FI) / Motherboard / ATX / LGA1200 Socket / Z490 / USB-C Gen2, USB 3.2 Gen 1, USB 3.2 Gen 2 / Gigabit LAN, 5 Gigabit Ethernet, Wi-Fi, Bluetooth / onboard graphics (CPU required) / HD Audio (8-channel) | 90MB12R0-M0EAY0
Please sign in so that we can notify you about a reply
ASUS ROG MAXIMUS XII HERO (WI-FI) / Motherboard / ATX / LGA1200 Socket / Z490 / USB-C Gen2, USB 3.2 Gen 1, USB 3.2 Gen 2 / Gigabit LAN, 5 Gigabit Ethernet, Wi-Fi, Bluetooth / onboard graphics (CPU required) / HD Audio (8-channel) | 90MB12R0-M0EAY0
Description
ROG MAXIMUS XII HERO is the perfect foundation to the ROG. It's a motherboard that packs substantial power, smart cooling and faster memory support under a stealthy skin. Loaded with renowned ROG features, from AI overclocking and AI cooling to attention-grabbing Aura Sync illumination, MAXIMUS XII HERO is ready to perform and crafted for customization.
ASUS ROG MAXIMUS XII HERO (WI-FI) / Motherboard | 90MB12R0-M0EAY0
Special Features
- Superior cooling
- VRM heatsink
- Large diameter heat pipe
- High-conductivity thermal pad
- Extended VRM heatsink
- M.2 heatsink
- Grow your gaming world
- Wi-Fi 6
Product features
- Superior cooling
The extra-large armor heat sinks also cover multiple M.2 slots. Featuring premium components and multiple fan headers, MAXIMUS XII HERO is fully armed to provide a good foundation for gaming systems. - VRM heatsink
A VRM heatsink is placed on the MOSFETs and chokes, and the embedded heat pipe connects to the aluminum I/O cover. - Large diameter heat pipe
The U-shaped design provides rapid and even heat transfer from the VRM to the extended VRM heatsink. - High-conductivity thermal pad
The high-quality thermal pad improves overall heat transfer from the system by bridging the heat generated by the power stages to the heatsink. - Extended VRM heatsink
The extended heatsink at the end of heat pipe increases thermal mass to offset the additional heat generated by high power consumption. - M.2 heatsink
A dedicated heatsink keeps the triple M.2 SSDs at the optimal operating temperature for consistent performance and reliability. - Grow your gaming world
Gear up with ROG components, from graphics and monitors to mice and keyboards. And up your game with complementary aesthetics, control and compatibility. The ROG ecosystem is more extensive than any competing brand, so enjoy greater choice as your system expands. - Wi-Fi 6
On-board Wi-Fi 6 (802.11ax) supports ultra-fast wireless speeds, improved capacity and better performance in dense Wi-Fi environments, providing exceptional online gaming experiences. - Better optimization
ROG provides the tools needed to optimize your system quickly and easily. For those who relish complete control, the UEFI BIOS offers advanced customization options so you can tweak every aspect of your system.
Product Specification
| Product Type | Motherboard - ATX |
| Chipset Type | Intel Z490 |
| Processor Socket | LGA1200 Socket |
| Max Processors Qty | 1 |
| Compatible Processors | (supports 10th Generation Intel Core / Pentium Gold / Celeron) |
| Max Size | 128 GB |
| Technology | DDR4 |
| Bus Clock | 2400 MHz, 2133 MHz, 2666 MHz, 2800 MHz (O.C.), 2933 MHz (O.C.), 3000 MHz (O.C.), 3200 MHz (O.C.), 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4500 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4600 MHz (O.C.), 4700 MHz (O.C.), 4800 MHz (O.C.) |
| Supported RAM Integrity Check | Non-ECC |
| Registered or Buffered | Unbuffered |
| Features | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
| Type | HD Audio (8-channel) |
| Audio Codec | SupremeFX (S1220) |
| Compliant Standards | High Definition Audio, DTS Sound Unbound |
| Network Controller | Intel I219V / Aquantia AQC111C / Intel AX201 |
| Network Interfaces | Gigabit Ethernet, 5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.1 |
| Expansion Slots | 1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 3.0 x16 (dual x8 mode; single card: x16 mode) ¦ 1 x PCIe 3.0 x16 (x4 mode (auto turn-off if M.2 is occupied)) ¦ 3 x PCIe 3.0 x1 |
| Storage Interfaces | SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2 ¦ PCIe 3.0 -connectors: 2 x M.2 |
| Interfaces | 1 x LAN (Gigabit Ethernet) ¦ 1 x LAN (5Gigabit Ethernet) ¦ 1 x TOSLINK ¦ 4 x USB 3.2 Gen 1 ¦ 3 x USB 3.2 Gen 2 ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x HDMI ¦ 1 x USB-C Gen2 ¦ 2 x USB 2.0 |
| Internal Interfaces | 4 x USB 2.0 - header ¦ 1 x USB 3.2 Gen 2 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x audio - header ¦ 1 x speaker - header ¦ 1 x Thunderbolt - header |
| Power Connectors | 4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector |
| BIOS Type | AMI |
| BIOS Features | BIOS FlashBack, UEFI BIOS |
| Sleep / Wake Up | Wake on LAN (WOL), wake on PME |
| Hardware Features | Jack retasking, ASUS Q-Design, Q-DIMM, ASUS EZ DIY, Q-LED, Q-Slot, ASUS Extreme Engine Digi+, CrashFree BIOS 3, ASUS Q-Connector, audio jack detect technology, NVIDIA 2-way SLI Technology Support, Intel Turbo Boost Technology 2.0, ASUS ROG Extreme OC, Q-Code, SupremeFX Shielding technology, AMD CrossFireX technology support, AMD 3-way CrossFireX technology support, Preboot eXecution Environment (PXE), Clear CMOS Button, ASUS SafeSlot, Intel Optane Memory Ready, Sonic Radar III, Sonic Studio III, M.2 heatsink, pre-mounted I/O shield, Intel Turbo Boost Max Technology 3.0, ASUS Aura Sync, Armoury Crate, ASUS OptiMem III, FlexKey button, ASUS ProCool II, GameFirst VI, ESS ES9023 + RC4580 |
| Included Accessories | External antenna, ROG fan stickers, 2 x M.2 screws, RGB (RGBW) LED strip extension cable, MOS cooling kit, ROG thank you card, RGB Addressable LED extension cable, ROG logo plate sticker, Q-Connector, rubber pad, ROG key chain |
| Cables Included | 4 x Serial ATA cable |
| Software Included | Drivers & Utilities, ASUS AI Charger, ROG CPU-Z, ROG Mem TweakIt Utility, ASUS AI Suite III, ASUS EZ Update, Overwolf, ASUS EZ Flash 3, WinRAR, ASUS ROG RAMCache III, Sonic Studio Virtual Mixer, BullGuard Internet Security (1 year licence) |
| Width | 30.5 cm |
| Depth | 24.4 cm |
| Service & Support | Limited warranty - 3 years |
Features - Asus - 90MB12R0-M0EAY0
More Details
Product Code
03:140596
EAN Code
4718017664097
Manufacturer
Asus
