ASUS TUF Gaming ARGB PWM - System fan and lighting hub | 90DA00C0-B09000
Please sign in so that we can notify you about a reply
Product Features
- Efficient power system
Equipped with 2 x 15-pin serial ATA power connectors, the hub ensures reliable and optimal power distribution to all connected components. - Versatile connectivity options
Supports both 4-pin PWM and 3-pin ARGB connectors, allowing for flexible customization of fan speeds and RGB lighting effects. - Advanced safety features
Includes overcurrent and short circuit protection mechanisms, providing users with peace of mind during operation. - User-friendly installation
Designed with a magnetic fixture, facilitating easy mounting and installation without the need for additional tools. - Real-time status monitoring
Features an LED indicator that provides visual feedback on fan status, enabling easy tracking of performance.
Special Fetures
- Provides 6 fan channels for cooling options
- Features LED indicator for monitoring fan status
- Includes pulse-width modulation support for efficient fan control
- Offers overcurrent and short circuit protection for safety
- Equipped with a magnetic fixture for installation
Product Specification
| Product Type | System fan and lighting hub |
| Width | 11.5 cm |
| Depth | 6.9 cm |
| Height | 1.77 cm |
| Weight | 81.5 g |
| Heatsink & Fan | |
| Power Connector | 2 x 15-pin serial ATA power connector |
| Rated Voltage | 12 V |
| Interface Provided | |
| Connector Provided | 3 pin ARGB x 6 <br /> 4 pin PWM x 6 |
| Miscellaneous | |
| Features | Pulse-width modulation (PWM) support, LED indicator, overcurrent protection, short circuit protection, magnetic fixture, 6 fan channels |
Features - Asus - 90DA00C0-B09000
More Details
Product Code
04:504442
EAN Code
4711387509777
Manufacturer
Asus
