ASUSTOR Lockerstor 4 Gen2 AS6704T - NAS server - 4 bays - SATA 6Gb/s - RAID RAID 0, 1, 5, 6, 10, JBOD - RAM 4 GB - 2.5 Gigabit Ethernet - iSCSI support | 90-AS6704T00-MD30

90-AS6704T00-MD30
861.92
(1,025.68 inc. VAT)
Availability: 21 item(s)
Standard DeliveryStandard delivery within 4 to 8 business days.
Find similar
Delivery
Payment options
Product Code04:408274 EAN Code4710474831432 ManufacturerAsus

Product Features

  • Powered by the 10 nm Intel Jasper Lake Celeron Quad-Core processors
    The Lockerstor Gen2 comes with Intel's Quad-Core Celeron CPUs. The N5105 comes with Intel 10 nm technology and is up to 31% faster than Gemini Lake SoCs. The Celeron N5105 is clocked at 2.0 GHz with 2.9 GHz, enabling efficient content creation with the added flexibility of 10-Gigabit Ethernet upgrades.
  • Four M.2 slots - have your cake and eat it too
    The Lockerstor Gen2 series of NAS devices come with four M.2 slots for caching or storage or both. Either use all slots for one purpose or mix and match depending on your needs. Four M.2 SSD slots bring a number of custom scenarios to your NAS when it comes to accelerating your storage.
  • Keeping cool
    With up to four SSDs, a considerable amount of heat can be generated. With extra ventilation, the Lockerstor Gen2 ensures that all components in your NAS receive cooling.
  • Removing your storage constraints
    Edit videos directly on your NAS with Adobe Premiere or Final Cut Pro. Both applications, as well as the full suite of Adobe software are supported on an ASUSTOR NAS ensuring that the SSD on your laptop is no longer a constraint.
  • Creativity knows no bounds
    Your ASUSTOR NAS can work as a hybrid cloud that enables data accessibility both locally and through public cloud providers, ensuring easy collaboration regardless of location.
  • More efficient than ever before
    Easily Transcode 10-bit 4K H.265 media with hardware decoding with unbelievably smooth video playback in LooksGood for the ultimate in 4K enjoyment.
  • 24/7 reliability and durability
    All ASUSTOR NAS are designed for and are suitable for 24/7 use. ASUSTOR NAS devices have also undergone rigorous tests, such as drop tests and burn tests to test durability in extreme conditions. Heatsinks were added to sensitive components to dissipate heat, helping to maintain the longevity of the device.
  • Protected from ransomware
    The Lockerstor comes with the most up-to-date version of ADM to help protect against ransomware attacks. With Snapshot Center and Btrfs providing efficient snapshots to easily restore lost data. Other security features found on the Lockerstor are the ability to create one or more replacement administrator accounts, a firewall by ADM Defender that features black and white lists and the ability to change default ports, disable SSH and Terminal to prevent remote attacks. MyArchive cold storage hard drive security can also be increased by implementing AES 256bit encryption.
  • Protected from the inside and out
    Protect your data from loss, damage and attacks with the ASUSTOR NAS. An ASUSTOR NAS is better protected by running the Linux-based ADM, employing a built-in firewall, ClamAV Antivirus, MyArchive and ADM's various backup tools help protect ransomware even better.
  • Exclusive MyArchive Cold Backup technology, unlimited capacity expansion
    MyArchive cold storage technology turns NAS hard drives into removable storage archive drives. Directly insert a MyArchive hard drive into a free bay inside your NAS to easily access, backup and share terabytes of content.

Special Fetures

  • Quad-Core 10 nm Intel Celeron N5105 CPU - 31% more performance over Gemini Lake
  • Superfast 2.5-Gigabit Ethernet ports
  • Flexible PCIe slot for 10GbE NICs or M.2 SSDs
  • Supports PCIe 3.0 SSDs for up to twice the performance of PCIe 2.0
  • Uses DDR4-2933 with 40% more performance
  • USB 3.2 Gen2 ports - 10Gbps speed
  • Enjoy, download, upload and stream content with 4K transcoding
  • Increased ventilation for SSDs
  • Supports wake on LAN and Wake on WAN

Product Specification

Device TypeNAS server
Host Connectivity2.5 Gigabit Ethernet
Total Storage Capacity0 GB
Installed Devices / Modules Qty0 (installed) / 4 (max)
Width17 cm
Depth23 cm
Height18.55 cm
Weight2.94 kg ()
Built-in DevicesLed panel, IR sensor, 1 x 120 mm fan
Processor / Memory
Processors Installed1 x Intel Celeron N5105 2 GHz
Number of CoresQuad-Core
Max Supported Qty1
Max Turbo Speed2.9 GHz
RAM4 GB (installed) / 16 GB (supported) - DDR4
Flash Memory Installed8 GB
Storage Controller
TypeRAID
Interface TypeSATA 6Gb/s
RAID LevelRAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD
Networking
Data Link Protocol100Mb LAN, GigE, 2.5 GigE
Network / Transport ProtocolTCP/IP, FTP, SMB, DDNS, NFS, SFTP, HTTP, HTTPs, IPv4, IPv6, CIFS, TFTP
Remote Management ProtocolSNMP, HTTP, HTTPS, SSH, SFTP, LDAP, Syslog
Network Services CompatibilityMicrosoft Active Directory (AD), DDNS, Microsoft CIFS, FTP, Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), SFTP, Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0)
PerformanceMaximum iSCSI target: 256 ¦ Maximum iSCSI LUN: 256 ¦ Maximum number of users: 4096 ¦ Maximum number of groups: 512 ¦ Maximum number of shared folders: 512 ¦ Maximum concurrent connections: 512
FeaturesFirewall protection, VLAN support, E-mail alert, Jumbo Frames support, SMS alert, UPnP Media Server, online RAID level migration, cloud backup, VPN Server, system log, VPN client, black list, white list, HiDrive support, Rsync compatible, RADIUS Server, Disk S.M.A.R.T. Scan, SSD read-only Cache, SSD read-write cache, LUN mapping, multipath IO (MPIO), UPS compatible, user quota, connection monitoring, Btrfs snapshots support, USB key decryption support, target masking, persistent (SCSI-3) reservations, scheduled bad block scans, FTP backup, external backup, one-touch backup, EZ Sync, SNMP server, syslog server
Encryption AlgorithmSSL, TLS, 256-bit AES
Compliant StandardsIEEE 802.3ad (LACP), UPnP
Expansion / Connectivity
Expansion Bays4 (total) / 4 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots4 (total) / 4 (free) x M.2
Interfaces2 x 2.5 Gigabit Ethernet - RJ-45 ¦ 2 x USB 3.2 Gen 2 - Type A ¦ 1 x HDMI output
Miscellaneous
FeaturesAutomatic sleep mode, Smart Fan
Compliant StandardsVCCI, C-Tick, BSMI, CCC, FCC, KCC, BIS, UKCA
Power
Power DeviceExternal power adapter
Voltage RequiredAC 100-240 V
Power Consumption Operational35 Watt
Power Consumption Stand by0.88 Watt
Power Provided90 Watt
Software / System Requirements
Software IncludedYandex, Oracle VirtualBox, Clam Antivirus, ASUSTOR Portal
OS RequiredUNIX, Apple MacOS, Linux, FreeBSD, Microsoft Windows Server 2003, Microsoft Windows Server 2008, Microsoft Windows Server 2012, Microsoft Windows XP / Vista / 7 / 8 / 10, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022
Manufacturer Warranty
Service & SupportLimited warranty - 3 years
Environmental Parameters
Min Operating Temperature0 °C
Max Operating Temperature40 °C
Humidity Range Operating5 - 95% RH (non-condensing)
Sound Emission17.6 dBA

Features - Asus - 90-AS6704T00-MD30

More Details
Product Code
04:408274
EAN Code
4710474831432
Manufacturer
Asus
