ATEN VanCryst VM0808HB 8 x 8 True 4K HDMI Matrix Switch - Video/audio switch - desktop, rack-mountable | VM0808HB
ATEN VanCryst VM0808HB 8 x 8 True 4K HDMI Matrix Switch - Video/audio switch - desktop, rack-mountable | VM0808HB
€1540.03 inc. VAT
VM0808HB
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Special Fetures
- Connects any of 8 HDMI sources to any of 8 HDMI displays
- Supports True 4K resolutions up to 4096 x 2160 @ 60Hz (4:4:4)
- Multiple control methods - system management via front-panel pushbuttons, IR remote, RS-232 control, and Web GUI/Telnet via Ethernet connections
- HDMI (3D, Deep Color, 4K) and HDCP 2.2 compatible
Product Specification
| Device Type | Video/audio switch |
| Enclosure Type | Desktop, rack-mountable 1U |
| Subtype | HDMI |
| Performance | Data transfer rate: 18 Gbps |
| Max Resolution | 4096 x 2160 / 3840 x 2160 @ 60 Hz |
| Max Video Bandwidth | 600 MHz |
| Features | Firmware upgradable, 3D support, 4K resolution support, metal housing, Dolby TrueHD support, DTS-HD Master Audio support, EDID Expert |
| Compliant Standards | HDCP 2.2 |
| Built-in Devices | Status LCD |
| Expansion / Connectivity | |
| Interfaces | 8 x HDMI input ¦ 8 x HDMI output ¦ 1 x serial (RS-232) DB-9 management ¦ 1 x management (LAN) RJ-45 ¦ 1 x remote control (IrDA) mini-jack |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V |
| Power Consumption Operational | 38.1 Watt |
| Miscellaneous | |
| Included Accessories | Remote control, IR receiver |
| Rack Mounting Kit | Included |
| Compliant Standards | FCC Part 15, RoHS, CEC |
| Dimensions & Weight | |
| Width | 43.24 cm |
| Depth | 26.23 cm |
| Height | 4.4 cm |
| Weight | 3.99 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 80% (non-condensing) |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 60 °C |
Features - Aten - VM0808HB
More Details
Product Code
03:217871
EAN Code
4719264646836
Manufacturer
Aten
