ATEN VS0801H / Video/audio switch / 8 x HDMI / desktop | VS0801H
VS0801H
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Special Features
- Allows up to eight HDMI sources to be connected to one HDMI display
- Quick and easy switching between HDMI sources via front panel pushbuttons or IR remote control
- Built-in bi-directional RS-232 serial port for high-end system control
- Up to 60 Hz refresh rate
- Long-distance transmission
- Superior video quality
- Supports 12-bit deep color for HDMI formats
- Plug and play
- DDC compatible
- HDMI compliant
- HDCP 1.1 compliant
- HDMI CEC compliant
- Signaling rates up to 2.25 Gbits in support of 1080p display
- All-metal casing
- Power on detection
- Easy and affordable way to add eight HDMI inputs to your home theater system
- Rack mountable
Product Specification
| Device Type | Video/audio switch - 8 ports |
| Enclosure Type | Desktop |
| Subtype | HDMI |
| Ports | 8 x HDMI |
| Max Resolution | 1920 x 1200 / 1080p @ 60 Hz |
| Features | HDCP compliant |
| Compliant Standards | HDCP 1.1 |
| Status Indicators | Port status |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 8 x HDMI ¦ 1 x RS-232 - 9 pin D-Sub (DB-9) management ¦ 1 x HDMI |
| Power | Power |
| Power Device | External power adapter |
| Miscellaneous | Miscellaneous |
| Included Accessories | Remote control |
| Rack Mounting Kit | Included |
| Dimensions & Weight | Dimensions & Weight |
| Width | 43.2 cm |
| Depth | 15.4 cm |
| Height | 4.4 cm |
| Weight | 1.8 kg |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 0 - 80% |
Features - Aten - VS0801H
More Details
Product Code
03:505249
EAN Code
4710423776326
Manufacturer
Aten
