AXIS AXIS P3245-LVE-3 License Plate Verifier Kit / Network surveillance camera / dome / outdoor / colour (Day&Night) / 1920 x 1080 / 1080p / auto iris / vari-focal / audio / LAN 10/100 / MJPEG, H.264, HEVC, H.265, MPEG-4 AVC / PoE Class 3 | 02234-001
Please sign in so that we can notify you about a reply
Product Features
- Easy and cost-effective
Ideal for automated vehicle access control, AXIS P3245-LVE-3 consists of an Axis dome camera and preinstalled AXIS License Plate Verifier analytics. This easy-to-install, all-in-one camera kit captures license plates and verifies them against the allow and blocklist stored in the camera to determine if a vehicle can enter a controlled area. So, you can eliminate people-hours to man gates, and free up resources for other tasks. And, because all the processing and storage takes place in the camera, there's no need for expensive servers and bandwidth requirements are reduced. - Automated license plate reading - day and night
AXIS P3245-LVE-3 delivers sharp images for license plate reading in all environments - day and night. This vandal-resistant, IK10-rated camera is safe to use even when installed at lower, more accessible heights. Featuring shock detection, it will send an alarm when it's been hit. This camera delivers HDTV 1080p resolution and include Axis image enhancement technologies as well as OptimizedIR to ensure the ideal image settings for license plate reading - 24/7. - Flexible solution
This flexible, all-in-one camera kit supports different levels of security - from basic entry/exit to advanced access control. It offers built-in support for AXIS A1001 and AXIS A1601 Network Door Controller allowing you to integrate with credential management systems and install a card reader as backup. It offers easy integration with your video management software (VMS). And, the application's open API (application programming interface) lets you add tailor-made applications for more complex requirements.
Special Features
- All-in-one vehicle access control
- Support for allow and blocklist
- Vandal- and weather-resistant
- Built-in support for Axis network door controllers
- OptimizedIR for recognition in darkness
Product Specification
| Device Type | Network surveillance camera |
| Audio Support | Yes: two-way audio capability |
| Audio Formats | PCM, G.726, ADPCM, AAC-LC, LPCM, G.711, OPUS |
| Form Factor | Dome |
| Camera Mount Type | Wall mount, ceiling mount |
| Connectivity Technology | Wired |
| Width | 14.9 cm |
| Depth | 14.9 cm |
| Height | 10.4 cm |
| Weight | 800 g |
| Camera | Camera |
| Type | Colour - Day&Night - fixed - outdoor |
| Digital Video Format | MJPEG, H.264, HEVC, H.265, MPEG-4 AVC |
| Max Digital Video Resolution | 1920 x 1080 |
| Motion Detection | Yes |
| Video Modes | 1080p |
| Exposure Range | 2 sec - 1/66500 sec |
| Minimum Illumination | 0.1 lux - colour - F1.8 - 50 IRE ¦ 0.02 lux - B&W - F1.8 - 50 IRE ¦ 0 lux - IR |
| Infrared LEDs | Yes |
| Infrared Distance | 40 m |
| Video Capture | 1920 x 1080 @ 60 fps |
| Still Image Capture Resolution | 1080p |
| RAM | 1024 MB |
| Flash Memory | 512 MB |
| Features | Sharpness control, white balance, progressive scanning, saturation control, brightness control, contrast control, image mirror, Privacy Mask Function, full duplex audio, active tampering alarm, digital PTZ function, password protection, IR Corrected lens, Variable Bitrate (VBR), Audio Detection, OptimizedIR, audible alerts, Zipstream technology, remote focus, ONVIF (Profile S) support, ONVIF (Profile G) support, exposure control, Pixel Counter Support, infrared-cut filter, Forensic WDR, IP address filtering, exposure zone, secure boot, Corridor mode, ONVIF (Profile T) support, Adaptive Bitrate (ABR), Lightfinder 2.0 technology, user access log |
| Image Sensor | Image Sensor |
| Type | RGB CMOS 1/2.8" |
| Lens Construction | Lens Construction |
| Type | Vari-focal |
| Optical Zoom | 2.6 x |
| Focal Length | 3.4 mm - 8.9 mm |
| Lens Iris | F/1.8 auto iris (P-Iris) |
| Horizontal Field of View (degree) | 36 - 100 |
| Vertical Field of View (degree) | 20 - 53 |
| Panning | Panning |
| Range (degree) | -180 to +180 |
| Tilting | Tilting |
| Range (degree) | -75 to +75 |
| Interfaces | Interfaces |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, CIFS, SRTP, EAP, SFTP, SIP, LLDP, USGv6 |
| Expansion / Connectivity | Expansion / Connectivity |
| Ports | LAN/power - RJ-45 ¦ Audio line-in/microphone - terminal block |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous | Miscellaneous |
| Included Accessories | Cable gaskets, drill hole template, Resistorx T20 tool L-key, weathershield, connector guard, terminal block connectors |
| Compliant Standards | EN55024, EN 61000-6-1, ICES-003 Class A, NEMA Type 4X, EN 61000-6-2, IEC 60068-2-30, IEC 60068-2-27, IEC 60068-2-6, IK10, FCC Part 15 B Class A, IP66, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, EN 50121-4, IEC 62236-4, VCCI Class A, NMB-3 Class A, RCM, IS13252, IEC EN60529, AS/NZS CISPR 32 Class A, EN 55032 Class A, KCC KN32 Class A, IEC/EN 62471, IEEE 802.3af, IEEE 802.3at, KCC KN35, IEC/EN 62262, IEC/EN/UL 62368-1, IEEE 802.1x, NIST SP500-267 |
| Colour | White |
| Power | Power |
| Power Requirements | PoE Class 3 |
| Software / System Requirements | Software / System Requirements |
| Software Included | AXIS Video Motion Detection, AXIS Object Analytics, AXIS License Plate Verifier |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 65 °C |
| Relative Humidity (operating) | 0 - 95% (non-condensing) |
Features - AXIS - 02234-001
More Details
Product Code
CB61224
EAN Code
7331021075153
Manufacturer
AXIS
