AXIS C6110 - Dispatch console - SIP, RTP, SIP over TLS, SIPS - black | 02709-001
Please sign in so that we can notify you about a reply
Product Features
- Versatile connectivity options
The AXIS C6110 offers various network protocols including TCP, UDP, and IPv6. With a mini-phone 3.5 mm microphone jack, headset jack, and RJ-45 Ethernet port, it ensures seamless connectivity to different systems. - Robust audio performance
Equipped with advanced voice features such as echo cancellation, digital signal processing, and noise reduction, the AXIS C6110 consistently delivers clear audio during calls. - Efficient power consumption
The device consumes only 6 W when powered over Ethernet (PoE), making it energy-efficient and cost-effective while delivering solid performance. - Durable and eco-friendly design
Constructed from aluminum and 50% recycled plastic, the AXIS C6110 is designed for durability and environmental sustainability, ensuring a reliable option for extensive use. - Adaptable mounting options
This device can be easily mounted on a wall or placed on a desk, providing flexibility for installation in various settings and meeting different user preferences.
Special Fetures
- 7-inch display with 1024 x 600 pixels for clear visibility
- Integrated speakerphone enables hands-free communication
- Supports multiple VoIP protocols and voice codecs
- Features ambient light sensor and Push-to-Talk key
- Poe support allows for easy installation
Product Specification
| Product Type | Dispatch console |
| Body Colour | Black |
| Body Material | Plastic casing, aluminium, 50% recycled plastic |
| Phone Features | |
| Speakerphone | Yes |
| Volume Control | Yes |
| Additional Functions | Push-to-Talk key, ambient light sensor |
| IP Telephony | |
| Main Features | Integrated Ethernet switch |
| VoIP | Yes |
| VoIP Protocols | SIP, RTP, SIP over TLS, SIPS |
| Voice Codecs | AAC-LC, G.711, G.726, ADPCM, WAV, MP3, Opus, G.711u-law, PCMU, PCMA, L16, Speex, G.726-32, G.722 |
| Quality of Service | Layer 3 TOS, Differentiated Services (DiffServ) |
| IP Address Assignment | DHCP |
| Security | EAP-TLS, IEEE 802.1X, PEAP-MSCHAPv2, TLS 1.2, TLS 1.3 |
| Power Over Ethernet (PoE) Support | Yes |
| Network Protocols | IPv4, IPv6, HTTP, HTTPS, SSL, TLS, FTP, SFTP, CIFS, SMB, SMTP, UPnP, SNMP, SNMPv2c, SNMPv3, DNS, DynDNS, NTP, RTSP, TCP, UDP, IGMP, RTCP, ICMP, ARP, SOCKS, SSH, NTCIP |
| Network Ports Qty | 1 x Ethernet 10Base-T/100Base-TX/1000Base-T |
| Voice Features | Digital signal processing (DSP), echo cancellation (ECN), Noise Reduction (NR), dual tone multi-frequency (DTMF) |
| Network Features | Class 3 PoE, full duplex speaker, Network Address Translation (NAT), TURN, ICE, STUN, IEEE 802.3af |
| Display | |
| Diagonal Size | 7" |
| Display Resolution | 1024 x 600 pixels |
| Processor | |
| Processor | i.MX 8M |
| Memory | |
| RAM | 1024 MB |
| Supported Flash Memory Cards | microSD |
| Miscellaneous | |
| Connections | Microphone jack / 4 pin XLR <br /> Headset jack / mini-phone 3.5mm <br /> Network / RJ-45 |
| Placing / Mounting | Desk-mountable, wall-mountable |
| Also Included | 1024 MB |
| Power | |
| Power Consumption | 6 W (PoE) |
| Dimensions & Weight (Base) | |
| Width | 29.5 cm |
| Depth | 13.2 cm |
| Height | 6.7 cm |
| Weight | 910 g |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
