AXIS M3068-P / Network surveillance camera / dome / colour (Day&Night) / 12 MP / 2880 x 2880 / fixed iris / fixed focal / audio / LAN 10/100 / MJPEG, H.264, H.265, MPEG-4 AVC / PoE | 01732-001
Product Features
- Forensic WDR, day/night functionality
Featuring Forensic WDR, AXIS M3068-P delivers clarity when there're both dark and light areas in the scene and outstanding 360° panoramic views. Plus, day/night functionality provides high quality black and white video with improved sensitivity in poor light. In smaller facilities it's possible to monitor the entire area with just one camera. Not only does the camera give you a complete and sharp overview, but it also allows you to zoom in and analyze live or recorded video footage. Whether an incident occurred in the middle of the space, or in a far corner, thanks to de-warping functionality you can always see distortion-free views of the specific area. AXIS M3068-P can deliver a variety of de-warped views, and you can fetch multiple, individually configured video streams simultaneously from the camera. - Sleek, sustainable design
This ultra-compact, PVC-free camera is made from recycled plastics and is designed to look discreet wherever it's installed. It features a sleek, no-dome design. Additionally, the camera's casing can be repainted to blend in seamlessly with specific surroundings. - This fixed mini-dome helps ensure smooth installation
It's factory-focused, so no focusing is required. And, thanks to digital roll functionality you can remotely adjust the rotation of the camera overview - no need to do it manually on the camera. Furthermore, Axis Zipstream technology compression significantly reduces bandwidth and storage requirements without compromising image quality.
Special Features
- 360° panoramic overview
- Forensic WDR, day/night functionality
- Small and discreet design
- Environmentally friendly materials
- Sleek, sustainable design
- Smooth installation
Product Specification
Device Type | Network surveillance camera |
Audio Support | Yes |
Form Factor | Dome |
Connectivity Technology | Wired |
Width | 10.1 cm |
Depth | 10.1 cm |
Height | 4.9 cm |
Weight | 300 g |
Camera | Camera |
Type | Colour - Day&Night - fixed |
Digital Video Format | MJPEG, H.264, H.265, MPEG-4 AVC |
Max Digital Video Resolution | 2880 x 2880 |
Motion Detection | Yes |
Exposure Range | 1 sec - 1/22000 sec |
Minimum Illumination | 0.32 lux - colour - F2.8 - 50 IRE ¦ 0.06 lux - B&W - F2.8 - 50 IRE |
Digital Video Capture Resolution | 384 x 288, 2048 x 1536, 2560 x 1920, 3840 x 2160, 160 x 160, 2880 x 2880, 256 x 144, 3200 x 1600, 192 x 72, 3584 x 2688 |
Frame Rate (max) | 30 frames per second |
RAM | 512 MB |
Flash Memory | 2 GB |
Features | Sharpness control, white balance, Wide Dynamic Range (WDR), AXIS Video Hosting System (AVHS), ONVIF support, infrared cut filter, Video Motion Detection Technology, active tampering alarm, digital PTZ function, 360° monitoring, Variable Bitrate (VBR), video analytics, Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, Pixel Counter Support, digest authentication, ONVIF (Profile T) support |
Image Sensor | Image Sensor |
Type | 12 MP RGB CMOS 1/1.7" |
Total Pixels | 4000 x 3000 |
Lens Construction | Lens Construction |
Type | Fixed focal |
Focal Length | 1.65 mm |
Lens Iris | F/2.8 fixed iris |
Horizontal Field of View (degree) | 185 |
Vertical Field of View (degree) | 185 |
Panning | Panning |
Range (degree) | -180 to +180 |
Interfaces | Interfaces |
Network Interface | Ethernet 10Base-T/100Base-TX |
Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, CIFS, EAP, SFTP |
Expansion / Connectivity | Expansion / Connectivity |
Ports | LAN/power - RJ-45 |
Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
Miscellaneous | Miscellaneous |
Compliant Standards | CISPR 22 Class A, EN55024, EN 61000-6-1, ICES-003 Class A, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, VCCI Class A, KN35, EN 62368-1, EN 55032 Class A, KCC KN32 Class A, IEEE 802.1x |
Colour | White |
Power | Power |
Power Requirements | PoE |
Power Device | 6.49 Watt |
Software / System Requirements | Software / System Requirements |
Software Included | Windows decoder 1-user licence |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - 3 years |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Relative Humidity (operating) | 10 - 85% (non-condensing) |
