AXIS Q9216-SLV Steel / Network surveillance camera / dome / ligature-resistant / colour (Day&Night) / 4 MP / 2304 x 1728 / 720p, 1080p / M12 mount / fixed iris / fixed focal / audio / HDMI / LAN 10/100 / MJPEG, H.264, HEVC, H.265, MPEG-4 AVC / PoE Plus |
AXIS Q9216-SLV Steel / Network surveillance camera / dome / ligature-resistant / colour (Day&Night) / 4 MP / 2304 x 1728 / 720p, 1080p / M12 mount / fixed iris / fixed focal / audio / HDMI / LAN 10/100 / MJPEG, H.264, HEVC, H.265, MPEG-4 AVC / PoE Plus | 01766-001
Description
AXIS Q9216-SLV is a compact and robust ligature-resistant (anti-ligature) corner-mount camera specially designed to provide a wide field of view and ensure no area is left uncovered. This low power consuming camera is ideal for high-security installations such as in prisons and psychiatric wards.
AXIS Q9216-SLV Steel / Network surveillance camera | 01766-001
Special Features
- Occupant safety and privacy
- Enhanced security features
- Compact and easy to install
- Easy to clean and maintain
- Anti-ligature, robust (IK10+)
- Corner camera - no blind spots
- WDR and invisible IR (940 nm)
- Zipstream supporting H.264 and H.265
Product features
- See it all - day and night
AXIS Q9216-SLV offers 4MP video quality and can cover 125 degrees horizontally and 95 degrees vertically, with no blind spots. Ideal in prison cells, it features 940 nm invisible IR illumination for unobtrusive surveillance in total darkness that won't irritate or provoke the occupant. Wide Dynamic Range (WDR) ensures clarity even when there's both dark and light areas in the scene. And, AXIS Zipstream technology with support for both H.264 and H.265 video compression significantly reduces bandwidth and storage requirements without compromising image quality. - Occupant safety and privacy
With a ligature-resistant (anti-ligature) design, this robust camera can help prevent self-harm, especially important in high-security installations. The vandal-resistant casing also offers IP66-rating for protection from dust and water. For added peace of mind, it includes a tampering alarm as well as shock and casing open detection so you can be informed if there's any attempt to interfere with the camera. It features a removable built-in microphone which can be mounted if audio surveillance is required. Furthermore, AXIS Q9216-SLV includes an indication LED to see if the camera is active or not as well as polygonal privacy masking ensuring occupant privacy is respected. - Enhanced security features
This high-performance camera is packed with advanced security functionality to prevent unauthorized access and safeguard your system. Signed firmware ensures that only authorized firmware is installed and guarantees that it hasn't been compromised. Furthermore, it includes a Trusted Platform Module to ensure secure storage of all cryptographic keys and certificates even in the event of a security breach. - Compact and easy to install
This compact camera offers simple and cost-effective installation. The chassis and mounting bracket are specially designed for versatile cable management and mounting options. It's possible to connect to various conduits and connectivity devices to the back of the camera. - Easy to clean and maintain
For ease of maintenance, the stainless-steel casing is IP66- and IP6K9K-rated to allow cleaning with high-pressure, high-temperature water jets. If the camera is severely soiled or defaced, the abrasion-resistant two-part front cover is easily removed, and the window can be cleaned more thoroughly.
Product Specification
Device Type | Network surveillance camera |
Audio Support | Yes: two-way audio capability |
Audio Formats | PCM, G.726, ADPCM, AAC-LC, LPCM, G.711, OPUS |
Camera Mount Type | Corner mount |
Connectivity Technology | Wired |
Width | 20.9 cm |
Depth | 17.6 cm |
Height | 13.1 cm |
Weight | 1.6 kg |
Type | Colour - Day&Night - fixed dome - ligature-resistant |
Digital Video Format | MJPEG, H.264, HEVC, H.265, MPEG-4 AVC |
Max Digital Video Resolution | 2304 x 1728 |
Motion Detection | Yes |
Video Modes | 720p, 1080p |
Exposure Range | 1/5 sec - 1/32500 sec |
Minimum Illumination | 0.23 lux - colour - F2.1 ¦ 0.05 lux - B&W - F2.1 ¦ 0 lux - IR |
Infrared LEDs | Yes |
Infrared Distance | 15 m |
Frame Rate (max) | 30 frames per second |
RAM | 1 GB |
Flash Memory | 512 MB |
Features | Sharpness control, digital image rotation, white balance, progressive scanning, saturation control, brightness control, contrast control, image mirror, Wide Dynamic Range (WDR), AXIS Video Hosting System (AVHS), Privacy Mask Function, Video Motion Detection Technology, digital PTZ function, Text Caption Overlay, password protection, shock detection, Variable Bitrate (VBR), Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, image overlay, exposure control, Pixel Counter Support, infrared-cut filter, IP address filtering, stainless steel housing, ONVIF (Profile T) support, Adaptive Bitrate (ABR) |
Type | 4 MP RGB CMOS 1/2.5" |
Type | M12 mount - fixed focal |
Focal Length | 2.4 mm |
Lens Iris | F/2.0 fixed iris |
Horizontal Field of View (degree) | 125 |
Vertical Field of View (degree) | 95 |
Video | HDMI |
Network Interface | Ethernet 10Base-T/100Base-TX |
Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, CIFS, SFTP, LLDP |
Ports | LAN/power - RJ-45 ¦ HDMI output - Type D ¦ Audio line-in/microphone - 3.5 mm jack ¦ Audio line out - 3.5 mm jack |
Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
Included Accessories | Microphone, Resistorx T20 tool, AVHS Authentication key, cable gaskets, AXIS Connector A 4-pin 2.5 straight |
Compliant Standards | CISPR 24, EN 61000-6-1, NEMA Type 4X, EN 61000-6-2, FIPS 140-2, IEC 60068-2-27, IEC 60068-2-6, FCC Part 15 B Class A, IP66, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, VCCI Class A, RCM, IS13252, IK10+, KN35, AS/NZS CISPR 32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, KCC KN32 Class A, IEC/EN 62471, IP69K, IEC 61000-6-1, IEC 61000-6-2, CAN/CSA-C22.2 No. 62368-1, UL 62368-1, EN 55035, CISPR 35, IEC/EN 60529 IP66, IEEE 802.1x, IP69, NIST SP500-267, EN 50130-5, ICES-3(A)/NMB-3(A), EN 50130-4 |
Colour | Stainless steel |
Power Requirements | PoE Plus |
Power Device | 10.8 Watt |
Software Included | Windows decoder 1-user licence |
Service & Support | Limited warranty - 3 years |
Min Operating Temperature | -20 °C |
Max Operating Temperature | 50 °C |
Relative Humidity (operating) | 10 - 85% |
