Belkin Thunderbolt 3 Dock Pro / Docking station / USB-C / Thunderbolt 3 / DP / GigE / 170 Watt | F4U097VF
Belkin Thunderbolt 3 Dock Pro / Docking station / USB-C / Thunderbolt 3 / DP / GigE / 170 Watt | F4U097VF
Description
The power, speed and pixels of Thunderbolt 3 are best in class, and this smart dock brings all the benefits in a single docking station solution. Compatible with Mac and Windows, simply connect your Thunderbolt 3 or USB-C laptop with the included Thunderbolt 3 cable to instantly create a powerful work station. Enjoy Ultra-High Definition monitor support, up to 40 Gbps transfer rates, 85W of power to your laptop, and support for multiple peripherals via Thunderbolt, USB-A, USB-C, Ethernet, SD and Audio ports, all through a single cable.
Belkin Thunderbolt 3 Dock Pro / Docking station | F4U097VF
Special Features
- Innovative solutions designed to suit both professional and at-home users
- Building on the success of the Thunderbolt 3 Express Dock HD named CES 2018 Best of innovation Awards Honoree
- Rigorous insertion testing guarantees quality, performance and durability
- Environmental tests ensure safety of all materials
Product features
- The ultimate work station
The power, speed and pixels of Thunderbolt 3 are best in class, and this smart dock brings all the benefits in a single docking station solution. Compatible with Mac and Windows, simply connect your Thunderbolt 3 or USB-C laptop with the included Thunderbolt 3 cable to instantly create a powerful work station. Enjoy Ultra-High Definition monitor support, up to 40 Gbps transfer rates, 85W of power to your laptop, and support for multiple peripherals via Thunderbolt, USB-A, USB-C, Ethernet, SD and Audio ports, all through a single cable. - Room for all your peripherals
Enjoy easy access to monitors, networks, power and peripherals with multiple ports available. - Thunderbolt 3 cable included
The dock connects to your Thunderbolt 3 or USB-C laptop through a single cable, which is included in the box. At 2.6ft / 0.8m, this cable is long enough to fit around furniture or reach further from the main outlet, to offer a more versatile desk configuration. - Sleek aluminum exterior
Durable aluminum casing protects the delicate circuitry inside the dock, while presenting a stylish, minimal exterior designed to suit any work space. - Dual high-definition monitor support
Thunderbolt 3 Dock Pro supports dual high-definition monitors for a versatile workspace. - Thunderbolt 3 laptop vs USB-C laptop monitor support comparison table
USB-C host performance will be limited. Note that not all USB-C ports support the full functionality of the USB Type-C standard. USB-C hosts may not support extended display to external monitors. - Ultra-High-Speed SD transfer
The SD (secure digital) card slot supports Ultra-High-Speed II (UHS-II), to transfer data quickly at up to 312 MG/s bus speed. Supporting standard SD cards, SDHC (High-Capacity) cards and SDXC (Extended-Capacity) cards, UHS-II can transfer a full day's camera footage three times faster than UHS-I. - Power to share
With the included 170W power supply unit, the Thunderbolt 3 Dock Pro provides up to 85W of power for a connected laptop. Also known as "upstream charging, " this keeps your laptop charged while in use, without a separate power cable.
Product Specification
Product Type | Docking station |
Enclosure Colour | Silver |
Max Resolution Details | 5120 x 2880 - 60 Hz |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Expansion Slots | SDXC UHS-II Memory Card |
Interfaces | 4 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x display / video - 20 pin DisplayPort ¦ 1 x USB-C 3.1 Gen 2 - 24 pin USB-C ¦ 1 x USB-C / Thunderbolt 3 - 24 pin USB-C with Power Delivery ¦ 1 x audio - headphones/microphone - mini-phone 3.5 mm ¦ 1 x USB-C / Thunderbolt 3 - 24 pin USB-C ¦ 1 x USB 3.1 Gen 1 - 9 pin USB Type A |
Input Device | SD card reader |
Cables Included | 1 x Thunderbolt cable - external - 80 cm |
Features | Dual display support, 5K Ultra HD, 85W power delivery |
Compliant Standards | Plug and Play, RoHS |
Power Device | Power adapter |
Voltage Required | DC 20 V |
Power Provided | 170 Watt |
OS Required | Windows 8 / 10, Apple MacOS X 10.12 - 10.14 |
Service & Support | Limited warranty - 2 years |
Min Operating Temperature | 5 °C |
Max Operating Temperature | 35 °C |
