Brother TD-4520TN / Label printer / DT/TT / Roll (11 cm) / 300 x 300 dpi / up to 127 mm/sec / USB 2.0, LAN, USB host, RS232C | TD4520TNZ1
Please sign in so that we can notify you about a reply
Brother TD-4520TN / Label printer / DT/TT / Roll (11 cm) / 300 x 300 dpi / up to 127 mm/sec / USB 2.0, LAN, USB host, RS232C | TD4520TNZ1
Description
Brother's TD-4520TN Thermal Transfer Label and Receipt printer provides the media flexibility, longevity and cost efficiency required for high volume printing at 300dpi resolution. This versatile device is ready to print on a wide range of media for barcodes, receipts and labels along with easy integration with the applications and database systems you rely on with ZPLII emulation, SAP & Bartender compatibility. Supporting a wide range of media to meet the needs of your operation, whether its longevity, abrasion resistance or even color, the TD-4520TN offers the required flexibility that's important to your commercial or industrial operation.
Brother TD-4520TN / Label printer | TD4520TNZ1
Special Features
- Large print width up to 105.7mm wide
- 300dpi print resolution
- Maximum up to 127mm/sec print speed
- USB Ver.20 (High Speed), RS232C, 10/100Base-TX Wired LAN
Product Specification
| Printer Type | Label printer - direct thermal / thermal transfer - monochrome |
| Print Speed | Up to 127 mm/sec |
| Connectivity Technology | Wired |
| Interface | USB 2.0, LAN, USB host, RS232C |
| Max Resolution (B&W) | 300 x 300 dpi |
| Language Simulation | ZPL, ZPL II, EPL, DPL |
| Features | Gap sensor, transmissive media sensor, label detection sensor |
| Barcodes | Code 93, Code 39, Code 49, GS1 DataBar, QR code, MaxiCode, Aztec code, Telepen, LOGMARS, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, MicroPDF417, Codabar, Code 11, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, China Post, Plessey, Code 128B, Code 128C, German Post, Code 128A, ITF-14, EAN-128, MSI |
| RAM Installed (Max) | 64 MB |
| Flash Memory | 128 MB |
| Media Type | Fanfold paper, continuous labels, die cut labels |
| Max Media Size | Roll (11 cm) |
| Min Media Size (Custom) | 20 mm |
| Max Media Size (Custom) | 112 mm |
| Media Sizes | Roll (4cm), Roll (11 cm) |
| Max Printing Width | 105 mm |
| Max Printing Length | 11430 mm |
| Media Thickness Range | 0.06 mm - 0.19 mm |
| Roll Maximum Outer Diameter | 127 mm |
| Roll Core Diameter | 25.4 mm, 38 mm |
| Networking | Print server |
| Security Protocols & Features | ARP, MAC address filtering |
| Connections | 1 x RS-232C - 9 pin D-Sub (DB-9) ¦ 1 x USB 2.0 ¦ 1 x USB host ¦ 1 x LAN |
| Cables Included | 1 x USB cable |
| Power Device | Power adapter - external |
| Voltage Required | AC 120/230 V |
| Frequency Required | 50/60 Hz |
| Software Included | Drivers & Utilities |
| OS Required | Linux, Microsoft Windows 7, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Windows 8, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Windows 8.1, Windows 10, Microsoft Windows Server 2016 |
| Service & Support | Limited warranty - 2 years - pick-up and return |
| Min Operating Temperature | 5 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 25 - 85% |
| Width | 28 cm |
| Depth | 20.4 cm |
| Height | 17.75 cm |
| Weight | 2.5 kg |
Features - Brother - TD4520TNZ1
More Details
Product Code
03:131441
EAN Code
4977766798563
Manufacturer
Brother
