Brother TJ-4120TN / Label printer / direct thermal / thermal transfer / Roll (12 cm) / 300 dpi / up to 178 mm/sec / USB 2.0, LAN, serial, USB host | TJ4120TNZ1
Please sign in so that we can notify you about a reply
Product Features
- Connectivity as standard
USB, USB Host, Serial and Ethernet are included as standard for the industrial printers. - In-built durability
The TJ industrial printer series offers performance you can rely on, even in the toughest production environments. The reliable thermal barcode printer has been built with you in mind and built to last, ensuring you enjoy years of hassle-free label printing. - High-quality thermal printing
The TJ-4120TN industrial barcode label printer offers 300 dpi resolution for easy-to-read text and barcodes, time after time. With high-quality product, packing and shipping labels, it is easy to maintain compliance throughout the supply chain. - Integrate with ease
With the Brother TJ series, there is no need to worry about integration. The industrial printers support various printer command languages, including ZPL2 emulation, making printer replacements as easy as possible - with minimal disruption.
Special Features
- Print speeds of up to 7 ips with 300 dpi resolution
- LED notification to indicate printer status
- Print width of up to 105.7 mm
- FBPL-EZD (EPL2, ZPL2, DPL) printer command languages supported
- High-capacity thermal transfer ribbon means fewer consumable changes
Product Specification
| Printer Type | Label printer - direct thermal / thermal transfer - monochrome |
| Printer | Printer |
| Print Speed | Up to 178 mm/sec - max speed |
| Connectivity Technology | Wired |
| Interface | USB 2.0, LAN, serial, USB host |
| Max Resolution (B&W) | 300 dpi |
| Language Simulation | ZPL II, EPL2, DPL |
| Features | Label detection sensor |
| Barcodes | Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, GS1 DataBar, QR code, MaxiCode, Aztec code, Telepen, LOGMARS, UPC-A, UPC-E, MicroPDF417, Code 128, Code 11, Interleaved 2 of 5, Postnet, PDF417, PLANET, TLC39, China Post, Plessey, EAN-14, ITF-14, EAN-128, EAN-8, EAN-13, MSI |
| RAM | RAM |
| RAM Installed (Max) | 128 MB |
| Flash Memory | Flash Memory |
| Flash Memory | 128 MB |
| Media Handling | Media Handling |
| Media Type | Continuous labels |
| Max Media Size | Roll (12 cm) |
| Min Media Size (Custom) | 20 mm |
| Max Media Size (Custom) | 120 mm |
| Media Sizes | Roll (4cm), Roll (11 cm), Roll (12 cm), Roll (2 cm) |
| Max Printing Width | 105.7 mm |
| Max Printing Length | 11430 mm |
| Roll Maximum Outer Diameter | 203 mm |
| Roll Core Diameter | 25.4 mm, 76.2 mm |
| Networking | Networking |
| Networking | Print server |
| Expansion / Connectivity | Expansion / Connectivity |
| Connections | 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x USB 2.0 ¦ 1 x LAN - RJ-45 ¦ 1 x USB host |
| Miscellaneous | Miscellaneous |
| Included Accessories | 1" ribbon paper core |
| Cables Included | 1 x USB cable |
| Features | 4 LED indicators |
| Software / System Requirements | Software / System Requirements |
| Software Included | Software Development Kit (SDK) |
| OS Required | Linux, Windows 8, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Windows 8.1, SuSE Linux Enterprise Server 12, Android 5.0 or later, Microsoft Windows Server 2016, CentOS 7.2, Apple iOS 9 or later, Red Hat Enterprise Linux 7.3, Apple macOS 10.12.x, Linux Fedora 24, Apple macOS 10.13.x, Microsoft Windows Server 2019, Apple macOS 10.14.x, Ubuntu 11.04 - 16.04, Apple macOS 10.15.x |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years - pick-up and return |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 25 - 85% (non-condensing) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 24.8 cm |
| Depth | 43.6 cm |
| Height | 27.4 cm |
| Weight | 9.2 kg |
Features - Brother - TJ4120TNZ1
More Details
Product Code
03:145772
EAN Code
4977766804721
Manufacturer
Brother
