Canon imageFORMULA DR-C230 / Document scanner / Duplex / Legal / 600 dpi x 600 dpi / up to 30 ppm (mono) / up to 30 ppm (colour) / ADF (60 sheets) / up to 3500 scans per day / USB 2.0 | 2646C003
Canon imageFORMULA DR-C230 / Document scanner / Duplex / Legal / 600 dpi x 600 dpi / up to 30 ppm (mono) / up to 30 ppm (colour) / ADF (60 sheets) / up to 3500 scans per day / USB 2.0 | 2646C003
Description
Designed to provide excellent value and performance to both small and medium sized organizations, the imageFORMULA DR-C230 comes fully equipped with the latest technologies and features required for simple capture and advanced workflows. The device is the latest high-performance desktop workgroup scanner in Canon's award winning series of imageFORMULA document scanners.The imageFORMULA DR-C230 is based on the successful imageFORMULA DR-C240, providing a compact, robust and reliable device with scanning speeds of 30 ppm/60 ipm. With its robust feeding mechanism the new scanner is capable of handling a variety of different media including scanning 6 mm thick passports through the 60-sheet document feeder. The compact imageFORMULA DR-C230 also includes various advanced image processing features, including text enhancement, automatic deskew and text orientation recognition, to help deliver exceptionally high quality images while saving users valuable time.
Canon imageFORMULA DR-C230 / Document scanner | 2646C003
Special Features
- Scanning speed of up to 30 ppm/60 ipm (single pass)
- Versatile feeding of various media including passports, thick ID card
- Robust & Reliable Design
- 60 sheet automatic document feeder
- Ultra-compact
- Efficient batch scanning with OCR function
Product Specification
| Type | Document scanner - desktop |
| Interface Type | USB 2.0 |
| Max Supported Document Size | Legal (216 x 356 mm) |
| Input Type | Colour |
| Grayscale Depth | 8-bit (256 grey levels) |
| Colour Depth | 24-bit (16.7 million colours) |
| Optical Resolution | 600 dpi x 600 dpi |
| Automatic Duplexing | Yes |
| Scan Element Type | CMOS / CIS |
| Bulb / Light Source Type | RGB LED array |
| Max Document Scan Speed B/W | 30 ppm |
| Max Document Scan Speed Colour | 30 ppm |
| Duty Cycle | 3500 scans per day |
| Scanner Speed Details | 30 ppm - black & white ¦ 30 ppm - colour |
| Scanner Features | Color Dropout, Ultrasonic Double Feed Detection, Double feed detection, Error Diffusion, Moire Reduction, automatic colour detection, automatic page size detection, blank page skipping, MultiStream Technology, Advanced Text Enhancement, Batch Separation, Smooth Background, Advanced Text Enhancement II, Prevent Bleed Through, Remove Background, Double Feed Release (DFR), Shadow Cropping, Deskew, Color Enhancement, Contrast Arrangment, Auto Resolution, Three-Dimensional Color Correction, Scan Area Setting, Adjustable Gamma Settings, Folio Mode |
| Compliant Standards | TWAIN, ISIS |
| Max Document Size | 216 mm x 3000 mm |
| Supported Document Type | Plain paper, business card, plastic card |
| Document Feeder Type | Automatic |
| Document Storage Capacity | 60 sheets |
| Interfaces | USB 2.0 - Type B |
| Cables Included | USB cable |
| Compliant Standards | RoHS |
| ENERGY STAR Certified | Yes |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational (Standby) | 19 Watt |
| Power Consumption Sleep | 1.4 Watt |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows 7 SP1, Microsoft Windows Server 2008 R2 SP1, Microsoft Windows Server 2012 R2, Windows 8.1, Windows 10, Microsoft Windows Server 2016, Apple MacOS X 10.10 - 10.12 |
| Width | 29.1 cm |
| Depth | 25.3 cm |
| Height | 23.1 cm |
| Weight | 2.8 kg |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 32.5 °C |
| Humidity Range Operating | 20 - 80% |
