Cisco Aironet 4800 / Radio access point / Wi-Fi 5 / 2.4 GHz, 5 GHz | AIR-AP4800-E-K9
Product Features
- Instant network analysis
Intelligent Capture probes the network and provides DNA Center with deep analysis. The software can track over 240 anomalies and instantaneously review all packets on demand, emulating the onsite network administrator. Intelligent Capture allows for more informed decisions on your wireless networks. - Issue detection
With a radio designed solely for security, the Aironet 4800 is a sentry that stops rogue agents attempting to gain access to your network. This dedicated radio constantly monitors the wireless network looking for anything that can cause a threat or interfere with performance. - Built-in hyperlocation
When combined with Operational Insights, the integrated radio for hyperlocation provides granular data by making it possible to monitor and track devices to within three meters. Hyperlocation helps both employees and guests with the application-enabled indoor wayfinding and navigation feature. - Four internal radios
Why does the Aironet 4800 need four built-in radios? The radios allow the access point's features to simultaneously help securely cover your network, provide real-time analytics and wayfinding, and offer high-quality Wi-Fi. - Better performance for many client devices
The 4800 supports 802.11ac Wave 2. But it also goes beyond the Wi-Fi standard with innovations that provide a better user experience while automatically increasing network capacity in high-density scenarios.
Special Features
- Instant network analysis
- Issue detection
- Built-in hyperlocation
- Four internal radios
- Better performance for many client devices
Product Specification
Device Type | Radio access point |
Ruggedized Design | Indoor |
Width | 22 cm |
Depth | 25 cm |
Height | 7.35 cm |
Weight | 2.5 kg |
Processor / Memory / Storage | Processor / Memory / Storage |
RAM | 1 GB |
Flash Memory | 256 MB |
Networking | Networking |
Form Factor | External |
Connectivity Technology | Wireless |
Data Transfer Rate | 5.2 Gbps |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
Frequency Band | 2.4 GHz, 5 GHz |
Capacity | Spatial streams: 3 |
Status Indicators | Boot State, error, status, operation mode |
Features | Wi-Fi Multimedia (WMM) support, CleanAir technology, Maximum Ratio Combining (MRC), 4T4R MIMO technology, cyclic shift diversity (CSD), packet aggregation A-MPDU, packet aggregation A-MSDU, ClientLink 4.0 technology, Dynamic Frequency Selection (DFS) |
Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3ad (LACP), IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11n, IEEE 802.11k, IEEE 802.11ac, IEEE 802.11w, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.3bz |
Aerial | Aerial |
Antenna | Internal |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | 2 x 1/2.5/5GBase-T - RJ-45 ¦ 1 x 1000Base-T (auxiliary) - RJ-45 ¦ 1 x management - RJ-45 |
Miscellaneous | Miscellaneous |
Included Accessories | Mounting brackets |
Compliant Standards | VCCI, ICES-003, FCC Part 15.247, RSS-102, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.107, FCC Part 15.109, FCC Part 15.407, EN 60601-1-2, ARIB STD-T66, ARIB STD-T71, Directive 93/42/EEC, EN 300 328, FCC OET Bulletin 65c, EN 301 489-1, RSS-247, EN 50155, EN 301 893, CAN/CSA-C22.2 No. 60950-1, EMI Class B, EN 301 489-17 |
Software / System Requirements | Software / System Requirements |
Software Included | Cisco Unified Wireless Network Software Release 8.7 or later, Cisco IOS XE 16.9 |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - advance hardware replacement - lifetime - response time: 10 days |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 - 90% (non-condensing) |
