Cisco 4G/3G Omnidirectional Dipole Antenna / Antenna / cellular / 2 dBi / omni-directional / indoor / raven black / for P/N: C819HG-LTE-MNA-K9, C898EAG-LTE-GA-K9 | 4G-LTE-ANTM-D=
Please sign in so that we can notify you about a reply
Product Features
- Articulating joint
It can be rotated 360 degrees and is capable of maneuvering into three stop positions - 0 degrees, 45 degrees, and 90 degrees. - Male threaded Neill-Concelman (TNC) connector
It lets you directly mount the antenna to any Cisco 4G and Cisco 3G wireless Integrated Services Router (ISR) EHWIC with a TNC connector. The threads on the connector must comply with the ANSI 7/16-28 UNEF 2B thread specification.
Special Features
- Articulating joint
- Male threaded Neill-Concelman (TNC) connector
Product Specification
| Product Type | Antenna |
| Enclosure Colour | Raven black |
| Aerial | Aerial |
| Intended For | Cellular |
| Aerial Placing / Mounting | Indoor |
| Compatibility | LTE |
| Frequency Range | 824 - 894 MHz, 698 - 806 MHz, 925 - 960 MHz, 1710 - 1885 MHz, 1920 - 1980 MHz, 2110 - 2170 MHz, 2500 - 2690 MHz |
| Gain | 2 dBi |
| Directivity | Omni-directional |
| Voltage Standing Wave Ratio (VSWR) | 2.5:1 |
| Impedance | 50 Ohm |
| Cabling & Wiring | Cabling & Wiring |
| Connector Provided | 1 x TNC male |
| Compatibility Information | Compatibility Information |
| Designed For | P/N: C819HG-LTE-MNA-K9, C898EAG-LTE-GA-K9 |
Features - Cisco - 4G-LTE-ANTM-D=
More Details
Product Code
677Q120
EAN Code
0882658435423
Manufacturer
Cisco
