Cisco Catalyst 9200CX - Network Advantage - switch - compact - L3 - Managed - 8 x 10/100/1000 (PoE+) + 2 x 1000Base-T + 2 x 10 Gigabit SFP+ (uplink) - rack-mountable - PoE+ (240 W) | C9200CX-8P-2XGH-A

C9200CX-8P-2XGH-A
2,121.41
(2,524.48 inc. VAT)
Available on order: 7 item(s)
Standard DeliveryStandard delivery within 4 to 8 business days.Express DeliveryExpress delivery within 2 to 3 business days.
Find similar
Delivery
Payment options
Product CodeCN45134 EAN Code0889728448284 ManufacturerCisco

Product Features

  • Robust capacity
    With support for up to 16 virtual networks, 14,000 IPv4 routes, and dual-stack IPv4/IPv6 routing entries, the Cisco Catalyst 9200CX ensures comprehensive coverage for evolving network demands.
  • Advanced networking
    Featuring Layer 3 advanced switching, support for multiple routing protocols including EIGRP, OSPF, and RIP, and comprehensive Quality of Service (QoS) capabilities, this switch is designed to handle complex networks.
  • High performance
    Equipped with a 4 GB RAM and 8 GB flash memory, the Cisco Catalyst 9200CX delivers exceptional performance, ensuring smooth and efficient operation even in high-demand environments.
  • Enhanced security
    MACsec support, Access Control List (ACL) support, and 802.1x authentication provide a secure network environment, safeguarding against unauthorized access and threats.
  • Flexible connectivity
    This switch offers a variety of connectivity options including RJ-45, SFP+ ports for uplinks, and a console (micro-USB), catering to diverse networking requirements and setups.

Special Fetures

  • Supports up to 16,000 Flexible NetFlow entries for comprehensive traffic analysis
  • Fanless design ensures silent operation, ideal for noise-sensitive environments
  • Rack-mountable with a compact form factor, saving valuable space in data centers
  • Compliant with a wide range of standards including IEEE 802.1D/Q/ae and more for broad compatibility
  • Manageable via CLI, NETCONF, RESTCONF, and SNMP for flexible administration

Product Specification

Device TypeSwitch - 8 ports - L3 - Managed
Enclosure TypeRack-mountable 1U
SubtypeGigabit Ethernet
Ports8 x 10/100/1000 (PoE+) + 2 x 1000Base-T + 2 x 10 Gigabit SFP+ (uplink)
Power Over Ethernet (PoE)PoE+
PoE Budget240 W
PerformanceSwitching capacity: 60 Gbps <br /> Forwarding rate: 44.64 Mpps
CapacityVirtual networks: 16 <br /> IPv4 routes: 14000 <br /> Direct IPv4 routes: 10000 <br /> Indirect IPv4 routes: 4000 <br /> IPv4 routing entries: 4000 <br /> IPv6 routing entries: 2000 <br /> Multicast scale: 1000 <br /> QoS scale entries: 1000 <br /> ACL scale entries: 1600 <br /> Flexible NetFlow entries: 16000 <br /> VLAN IDs: 4096 <br /> PVST instances: 128 <br /> STP Virtual Ports for PVST: 13000 <br /> STP Virtual Ports for MST: 13000 <br /> Switched virtual interfaces (SVIs): 1000 <br /> IP SGT binding scale: 8000 <br /> IPv4 bindings: 8000 <br /> SGT/DGT policies: 2000 <br /> SXP Sessions: 200 <br /> Flexible NetFlow entries: 16000 <br /> Buffer capacity (MB): 6
MAC Address Table Size32000 entries
Jumbo Frame Support9198 bytes
Routing ProtocolOSPF, RIP, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, OSPFv3, EIGRP for IPv6, PIM-SSM, policy-based routing (PBR), RIPng, MSTP, HSRP, IS-IS, MSDP, LISP, IS-ISv4
Remote Management ProtocolSNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2, CLI, NETCONF, RESTCONF, YANG
Encryption Algorithm256-bit AES
FeaturesFanless, QoS, Rapid PVST+, SRR, PXE support, RSPAN, Energy Efficient Ethernet, MIB, CoS, FNF, 802.1x authentication, DSCP support, MACsec support, SPAN, EEM, PIM, FHS, PVLAN support, CIR, ACL support, Cisco UADP 2.0, built-in ASIC, NetFlow, EEE, Preboot Execution Environment, Cisco StackWise Technology, BSR Mechanism, VRF, VXLAN, SGT caching, MACsec, CoPP, ZTP
Compliant StandardsIEEE 802.3, IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.1ae, IEEE 802.3at, IEEE 802.3af, IEEE 802.3bt
RAM4 GB
Flash Memory8 GB
Built-in DevicesRFID tag
Status IndicatorsBeaconing, status
Expansion / Connectivity
Interfaces8 x 1000Base-T RJ-45 PoE+ - 30 W <br /> 2 x 1000Base-T RJ-45 <br /> 2 x 10GBase-X SFP+ uplink <br /> 1 x USB 2.0 Type A <br /> 1 x console (micro-USB) Type B
Expansion Slots1 (total) / 1 (free) x SD Memory Card
Power
Power DeviceInternal power supply
Power Provided315 Watt
Voltage RequiredAC 100-277/ DC 120-418 V (50/60 Hz)
FeaturesHigh Voltage DC (HVDC)
Miscellaneous
Compliant StandardsPlug and Play, EN 61000-3-2, EN 61000-3-3, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35, EN 55035, EN 62368-1, IEC 62368-1, UL 62368-1
Software / System Requirements
Software IncludedCisco IOS XE 17.9 Universal
Dimensions & Weight
Width26.9 cm
Depth24.4 cm
Height4.4 cm
Weight2.99 kg
Manufacturer Warranty
Service & SupportLimited warranty - replacement - lifetime - response time: next business day <br /> Technical support - consulting - 90 days
Environmental Parameters
Min Operating Temperature-5 °C
Max Operating Temperature40 °C
Humidity Range Operating5 - 90% (non-condensing)
Min Storage Temperature-40 °C
Max Storage Temperature70 °C
Humidity Range Storage5 - 90% (non-condensing)
