Cisco Catalyst IE3100 Rugged Series / Switch / 8 x 10/100/1000 + 2 x combo Gigabit / DIN rail mountable | IE-3100-8T2C-E
Please sign in so that we can notify you about a reply
Product Features
- Incorporate within turnkey industrial solutions?
Deliver fully managed, secure, and reliable custom-built machinery by connecting individual devices within your industrial solution. - Join the circular economy
Invest in products that are designed, built, and delivered with sustainability in mind. The Catalyst IE3100 Rugged series eliminates the use of paint with anodization. - ??Protect your operations with best-in-class security?
??Reduce risk and defend your operations against cyberthreats with device authentication, access control, and network segmentation.
Special Features
- Incorporate within turnkey industrial solutions
- Join the circular economy
- Protect your operations with best-in-class security
Product Specification
| Device Type | Switch - 10 ports |
| Enclosure Type | DIN rail mountable |
| Ports | 8 x 10/100/1000 + 2 x combo Gigabit |
| Capacity | Queues per port (egress): 8 ¦ Unicast MAC addresses: 8000 ¦ IGMP groups: 512 ¦ VLAN groups: 256 ¦ IPv4 unicast indirect routes: 2000 ¦ STP instances: 128 |
| Remote Management Protocol | SNMP, NETCONF, RESTCONF, Modbus, DHCP |
| Features | Layer 2 switching, REP, MRP |
| Compliant Standards | IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 1588v2, IEEE 1613 |
| RAM | 4 GB |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 8 x 10/100/1000 Base-T RJ-45 ¦ 2 x 1000Base-TX ¦ 1 x console RJ-45 ¦ 1 x micro-USB mini-USB |
| Power | Power |
| Power Device | External power adapter |
| Power Provided | 12 - 48 V - 2 A |
| Miscellaneous | Miscellaneous |
| MTBF | 854,560 hours |
| Compliant Standards | EN55024, ICES-003 Class A, IEC 60068-2-30, IEC 60068-2-27, IEC 60068-2-6, EN 61131-2, IEC 60068-2-64, IEC 60068-2-14, IEC 60068-2-52, ISO 12944-6, IEC 60068-2-60, EN 50121-4, IP30, VCCI Class A, NEMA TS-2, China RoHS, RCM, EN 50121-3-2, EN 61326, IEC 60068-2-3, EN 61373, UL/CSA60950-1, AS/NZS CISPR 24, IEC/EN/EN61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 61000-4-9, IEC/EN 61000-4-29, IEC/EN 61000-6-1, IEC/EN 61000-6-2, IEC/EN 61000-6-4, AS/NZS CISPR 32 Class A, IEC 62368-1, EN 55032 Class A, EU RoHS, RFC768, RFC791, IEC 60079-0, IEC 60079-15, UL 121201, CSA C22.2 No. 213, UL/CSA 61010-2-201, IEC/EN 61010-2-201, UL/CSA 60079-0, IEC 60079-7, RFC783, RFC792, ODVA Class 2 Thin, UL/CSA 62368-1, FCC 47 CFR Part 15 B Class A, KN32/35, Class A, BSMI CNS13438, Class A, IEC/EN 61000-4-10 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 12.7 cm |
| Depth | 7.62 cm |
| Height | 11 cm |
| Weight | 860 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited hardware warranty - 5 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 85 °C |
Features - Cisco - IE-3100-8T2C-E
More Details
Product Code
CG80495
EAN Code
0889728463751
