Cisco Integrated Services Router 926 / Router / cable mdm / 4-port switch / GigE / WAN ports: 2 | C926-4P
Please sign in so that we can notify you about a reply
Special Features
- High availability and business continuity
- Consistent, high application performance levels
- Risk mitigation with multilevel security
- Feature consolidation for real estate, Capital Expenditures (CapEx), and management savings
- Unified control of wired and wireless networks from a common console for streamlined operations
- Remote configuration and management to keep local IT staff lean
Product Specification
| Device Type | Router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol | L2TP, RSVP, ICMP/IP, IPSec, FTP, DHCP, DNS, L2TPv3, DDNS, RTP, HTTP, HTTPs, cRTP |
| Routing Protocol | OSPF, RIP-1, RIP-2, BGP, EIGRP, HSRP, VRRP, NHRP, IGMPv3, GRE, OSPFv3, policy-based routing (PBR), BGP-4+, WCCP, Bidirectional Forwarding Detection (BFD), RSVP, STP, MGRE |
| Remote Management Protocol | Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Encryption Algorithm | DES, Triple DES, AES, SSL, PKI, 128-bit AES, 192-bit AES, 256-bit AES |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
| Features | NAT support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DiffServ support, MAC address filtering, Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Fair Queuing (WFQ), Access Control List (ACL) support, Quality of Service (QoS), Link Fragmentation and Interleaving (LFI), Dynamic Multipoint VPN (DMVPN), DHCP server, Virtual Route Forwarding-Lite (VRF-Lite), DNS proxy, DHCP relay, DHCP client, Management Information Base (MIB), Neighbor Discovery Protocol (NDP), VPN Server, Flexible NetFlow (FNF), DiffServ Code Point (DSCP) support, Storm Control, SmartPort technology, VPN client, Hierarchical Quality of Service (HQoS), Switched Port Analyzer (SPAN), Embedded Event Manager (EEM), Multigroup HSRP (MHSRP), Network-Based Application Recognition (NBAR), Network-Based Application Recognition (NBAR) 2, Performance Routing (PfR), Class-Based Traffic Shaping (CBTS), Class-Based Traffic Policing (CBTP), Class-Based Weighted Random Early Detection (CBWRED), Cisco IP Service-Level Agreement (IP SLA), Cisco Next Generation Plug-and-Play (NG PnP) Protocol |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, EN 61000-6-1, AS/NZS 60950-1, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, VCCI V-3, EN 61000-3-2:2006, EN 61000-3-3:2008, KN24, CNS13438:2006, EN 300 386 V1.6.1, CISPR 24:2010, EN 55024:2010, CISPR 22:2008, EN 300 386, TCVN 7189, EN 55032, CAN/CSA-C22.2 No. 60950-1, TCVN 7317, KN22:2009, ICES-003:2012 Issue 5 |
| Processor | 2.2 GHz |
| RAM | 1 GB |
| Flash Memory | 2 GB |
| Communications | Communications |
| Type | Cable modem |
| Digital Signaling Protocol | VDSL, ADSL2+ |
| Protocols & Specifications | ITU G.992.5 Annex B, ITU G.992.5 Annex J |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 1 x VDSL / ADSL2+ ¦ LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ USB 2.0: 1 x 4 pin USB Type A |
| Power | Power |
| Power Device | External power adapter - 30 Watt |
| Voltage Required | DC 12 V |
| Software / System Requirements | Software / System Requirements |
| OS Provided | Cisco IOS IP Base |
| Dimensions & Weight | Dimensions & Weight |
| Width | 25.91 cm |
| Depth | 17.78 cm |
| Height | 2.8 cm |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - advance parts replacement - 1 year - response time: 10 days |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Features - Cisco - C926-4P
More Details
Product Code
677QZ18
EAN Code
0889728172172
Manufacturer
Cisco
