Cisco Webex Codec Pro / Video conferencing device | CS-CODEC-PRO-K9
Please sign in so that we can notify you about a reply
Product Features
- Online meetings made simple
Webex brings people all over the globe together. It's like being there in person, even when you can't be. Join from any device, get HD quality audio and video, or share your screen. - Continuous collaboration in one place
Webex brings your work beyond the meeting. One secure app for video conferencing, group messaging, file sharing and whiteboarding. Support your team from start to finish.
Special Features
- Online meetings made simple
- Continuous collaboration in one place
Product Specification
| Device Type | Video conferencing device |
| Width | 43.6 cm |
| Depth | 23.1 cm |
| Height | 6.6 cm |
| Weight | 3.3 kg |
| Modem | Modem |
| Max Transfer Rate | 6 Mbps |
| Digital Signaling Protocol | H.323, SIP, H.245, H.460.18, H.460.19, BFCP |
| Data Compression Protocol | G.711, G.722, H.263, H.264, G.729AB, G.722.1 |
| Video Output | Video Output |
| Type | Codec board - rack-mountable |
| Supported Display Graphics | HDTV (1920x1080), HD (1280 x 720), UHD (3840 x 2160) |
| Digital Video Standard | High-Definition Multimedia Interface (HDMI) |
| Input Device | Input Device |
| Type | Remote control |
| Connectivity Technology | Wireless |
| Networking | Networking |
| Type | Network adapter |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, Bluetooth 4.0, IEEE 802.11ac |
| Network / Transport Protocol | TCP/IP, NTP, DHCP, DNS |
| Features | IPv6 support, Quality of Service (QoS), SSH support, URI Dialing, administrator's password, dual band, Network Timing Protocol (NTP), 2x2 MU-MIMO technology, CEC 2.0 support |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 6 x audio / video - HDMI input - 19 pin HDMI Type A ¦ 3 x audio / video - HDMI output ¦ 3 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 2 x network - Ethernet 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45 ¦ 2 x USB ¦ 1 x USB ¦ 8 x microphone - input ¦ 6 x audio - output |
| Miscellaneous | Miscellaneous |
| Compliant Standards | EN55024, FCC, EN 60950-1, FCC CFR47 Part 15 C, X.509, NRTL, EN 62311, Directive 2011/65/EU, Directive 2002/96/EU, EN 300.440, EN 300 328, EDID compatible, EN 301 489-1, FCC CFR47 Part 15 B Class A, EN 62479, Directive 2014/35/EU, Directive 2014/30/EU, EN 55032 Class A, EN 301 893, FCC CFR47 Part 15 E, Directive 2014/53/EU, EN 301 489-17 |
| Software / System Requirements | Software / System Requirements |
| Software Included | Cisco Collaboration Endpoint 9.4 |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% |
Features - Cisco - CS-CODEC-PRO-K9
More Details
Product Code
677QH39
EAN Code
0889728127431
Manufacturer
Cisco
