Cisco Integrated Services Router 1131X - Router 8-port switch - 1GbE - WAN ports: 2 - Wi-Fi 6 | C1131X-8PWE
Please sign in so that we can notify you about a reply
Product Features
- Next-generation connectivity
Get increased mobility and next-generation WAN and LAN options. Access Ethernet, DSL, 5G, and 802.11ax Wi-Fi. The 1000 series is ideal for use as customer premises equipment (CPE). - Automation deployment
Automate deployment, configuration, and management of the 1000 series with Cisco vManage. A centralized, highly visual dashboard simplifies and extends controls across the SD-WAN fabric and to the cloud edge. - Integrated enterprise-class security
Gain enterprise-class security. Cisco Umbrella, Encrypted Traffic Analytics, and advanced threat defense provide high-performance encryption, VPN, firewall, and URL filtering. Cisco Trust Anchor technology protects your network firmware from threats. - Multicloud capabilities
The 1000 series are the first fixed-configuration routers with the trusted Cisco IOS XE Software. Cisco IOS XE Software is optimized for cloud connectivity, enhanced visibility, and full-stack security, with robust multicloud capabilities.
Special Fetures
- Next-generation connectivity
- Automation deployment
- Integrated enterprise-class security
- Multicloud capabilities
Product Specification
| Device Type | Router - 8-port switch (integrated) |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Performance | SD-WAN IPsec throughput (1400 bytes, controller mode): 1889 Mbps <br /> SD-WAN IPsec throughput (IMIX, controller mode): 465 Mbps <br /> IPv4 forwarding throughput (IMIX): 1648 Mbps <br /> IPsec throughput (multi tunnel, IMIX): 470 Mbps <br /> Maximum encryption throughput (single tunnel, IMIX): 650 Mbps |
| Capacity | SD-WAN overlay tunnels scale: 200 <br /> IPsec IPv4 tunnels: 100 <br /> ACLs per system: 4000 <br /> Access Control Entries (ACEs) per system (IPv4): 10000 <br /> IPv4 routes: 280000 <br /> IPv6 routes: 260000 <br /> NAT sessions: 100000 <br /> Firewall sessions: 20000 <br /> Virtual Routing and Forwarding (VRF) instances: 1000 |
| Network / Transport Protocol | IPSec, IPv4, IPv6 |
| Remote Management Protocol | HTTP, HTTPS, CLI |
| Encryption Algorithm | AES, WPA2 |
| Authentication Method | RADIUS |
| Features | QoS, reset button, fanless, MRC, CSD, beamforming technology, packet aggregation A-MPDU, packet aggregation A-MSDU, AAA, DFS, TDD, MIP, 2x2:2 MU-MIMO technology, security slot (Kensington security lock compatible), BSS Coloring, FirstNet ready, TWT, remote firmware upgrade, SMS |
| Compliant Standards | IEEE 802.1x, Wi-Fi CERTIFIED 6, CISPR 24, EN 61000-3-2, EN55022, EN 61000-3-3, EN55024, UL 60950, CISPR 22, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-4-11, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, VCCI V-3, AS/NZS CISPR 22, CNS 13438, EN 301 489-7, EN 301 489-1, FCC CFR47 Part 22, FCC CFR47 Part 24, EN 300 386, EN 62368-1, IEC 62368-1, UL 62368-1, CSA 60950-1, CSA 62368-1, EN 301 489-24, EN 301 908-1, EN 301 908-2, EN 301 511, EN 301 908-13, ICES 003 |
| RAM | 8 GB |
| Flash Memory | 16 GB |
| Built-in Devices | GPS |
| Status Indicators | Status |
| Line Properties | |
| Line Coding Format | OFDMA |
| Expansion / Connectivity | |
| Interfaces | WAN: 2 x 1000Base-X - SFP (mini-GBIC) <br /> WAN: 2 x 1000Base-T - RJ-45 <br /> LAN: 8 x 1000Base-T - RJ-45 <br /> USB 2.0: 1 x 4 pin USB Type A <br /> Console: 1 x RJ-45 <br /> USB: 1 x 5 pin Micro-USB Type A |
| Power | |
| Power Device | External power adapter - 66 Watt |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 25 Watt |
| Miscellaneous | |
| Localisation | Bahrain, Oman, Saudi Arabia, United Arab Emirates, Israel, South Africa, Myanmar, Thailand, Ghana, Kenya, Uganda, Botswana, Kazakhstan |
| Software / System Requirements | |
| Software Included | Cisco Embedded Wireless Controller software image |
| Dimensions & Weight | |
| Width | 32.3 cm |
| Depth | 22.6 cm |
| Height | 4.19 cm |
| Weight | 2.17 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advance hardware replacement - 1 year - response time: 10 days |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 85% RH (non-condensing) |
Features - Cisco - C1131X-8PWE
More Details
Product Code
CI49094
EAN Code
0889728417716
Manufacturer
Cisco
