Cisco Catalyst IW9165E Rugged - Radio access point - 1GbE, 2.5GbE - Wi-Fi 6 - Bluetooth, Wi-Fi 6E - 5 GHz, 6 GHz - rail mountable | IW9165E-E-URWB
Please sign in so that we can notify you about a reply
Product Features
- Wi-Fi 6 (802.11ax)/Wi-Fi 6E ready
The IEEE 802.11ax standard, also known as High-Efficiency Wireless or Wi-Fi 6, builds on 802.11ac. IW9165 can support up to a 3.6 Gbps PHY data rate with 2x2 MIMO and two spatial streams. Wi-Fi 6E is Wi-Fi 6 "extended" into the 6 GHz frequency band, allowing the use of additional channels. IW9165 is Wi-Fi 6E ready, subject to approvals and regulations for the use of the 6 GHz spectrum by each country's regulatory agencies. - Multigigabit Ethernet
Multigigabit Ethernet supports speeds up to 2.5 Gbps. All speeds are supported on Category 5e cabling, as well as 10GBASE-T (IEEE 802.3bz) cabling. - GNSS
A built-in GNSS (Global Navigation Satellite System) receiver provides coordinates to track the location of the access point. - M12 adapter
The M12 adapter accessories give the flexibility to convert interfaces on the base unit into M12 interfaces, while retaining all the certifications.
Special Fetures
- Wi-Fi 6 (802.11ax)/Wi-Fi 6E ready
- Multigigabit Ethernet
- GNSS
- M12 adapter
Product Specification
| Device Type | Radio access point |
| Ruggedized Design | Indoor |
| Built-in Devices | GNSS receiver |
| Width | 15.2 cm |
| Depth | 12.4 cm |
| Height | 4.3 cm |
| Weight | 750 g |
| Processor / Memory / Storage | |
| RAM | 2 GB |
| Flash Memory | 1 GB |
| Networking | |
| Form Factor | DIN rail mountable |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 3.6 Gbps |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, Bluetooth 5.0 LE, IEEE 802.11ax (Wi-Fi 6E) |
| Frequency Band | 5 GHz, 6 GHz |
| Capacity | Spatial streams: 2 |
| Status Indicators | Port status, system |
| Features | High Availability, Dying Gasp support, surge protection, Wi-Fi Multimedia (WMM) support, reset button, rugged, workgroup bridge, secure boot, low power consumption, 2x2 MIMO technology, image signing, Cisco Trust Anchor module, Received Signal Strength Indication (RSSI) support, zero packet loss, Cisco Ultra-Reliable Wireless Backhaul (URWB), multipath operations (MPO), self-identifiable aerials (SIA) support |
| Encryption Algorithm | TLS, PEAP, TTLS, EAP-SIM, EAP-FAST, MSCHAPv2, EAP-GTC |
| Authentication Method | Extensible Authentication Protocol (EAP) |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.3bz, IEEE 802.11ax, Wi-Fi CERTIFIED 6, Wi-Fi CERTIFIED 6E |
| Aerial | |
| Antenna | External detachable |
| Gain Level | 15 dBi |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
| Communications Technology | Bluetooth Low Energy (LE) |
| Expansion / Connectivity | |
| Interfaces | 1 x 100/1/2.5GBase-T (UPOE) - RJ-45 ¦ 1 x 10/100/1000Base-T - RJ-45 ¦ 4 x aerial - RP-SMA ¦ 2 x GPIO ¦ 1 x management - RJ-45 |
| Miscellaneous | |
| Compliant Standards | EN 61000-6-1, RSS-102, ICES-003 Class A, EN 61000-6-2, EN 61000-6-4, IEC 60068-2-30, WEEE, IEC 60068-2-27, IEC 60068-2-6, EN 61000-4-29, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, EN 62311, EN 50121-4, IP30, IEC 61000-4-9, EN 50121-3-2, CISPR 11 class A, IEC 61000-4-17, FCC OET Bulletin 65c, EN 61373, CNS 13438 Class A, EN 300 386, EN 50155, IEC/EN 61000-4-3, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, EN 62368-1, IEC 62368-1, IEC/EN 61000-4-2, CISPR 32 Class A, EN 301 489-19, EN 55035, CISPR 35, IEC 61000-4-18, EN 301 489-1 V2.2.3, NCC LP0002:2018, KS C 9835:2019, EN 45545-3, DIN 5510-2, EN 301 489-17 V3.2.4, AS/NZ CISPR 32 Class A, CISPR 16 class A, KS C 9832:2019, KS X 3124, KS X 3126, AAR S9401, AREMA C&S Manual Section 11.5.1, FCC CFR Part 15.247, FCC CFR Part 15.407, RSS-247 Issue 5, AS/NZ 4268:2018 |
| Power | |
| Power Over Ethernet (PoE) Supported | UPOE / PoE+ |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advance hardware replacement - 1 year - response time: 10 days |
| Environmental Parameters | |
| Min Operating Temperature | -20 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 90% (non-condensing) |
Features - Cisco - IW9165E-E-URWB
More Details
Product Code
CJ29543
EAN Code
0889728567626
Manufacturer
Cisco
