Club 3D / Docking station / USB-C 3.2 Gen 1 / VGA, HDMI, DP / GigE / 100 Watt | CSV-1564W100
Συνδεθείτε για να μπορέσουμε να σας ειδοποιήσουμε σχετικά με μια απάντηση
Special Features
- Triple Display support
- SD- and micro SD slots work simultaneously
- Audio port (stereo), supports both micro- and head-phone
Product Specification
| Product Type | Docking station |
| Width | 35 cm |
| Depth | 7.5 cm |
| Height | 2 cm |
| Networking | Networking |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Compliant Standards | IEEE 802.3 |
| Expansion / Connectivity | Expansion / Connectivity |
| Expansion Slots | 1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x microSD |
| Interfaces | 2 x USB-C 3.2 Gen 1 - 24 pin USB-C ¦ 1 x USB-C 3.2 Gen 1 with Power Delivery 3.0 (100 W) - 24 pin USB-C ¦ 3 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 2 x USB 2.0 - 4 pin USB Type A ¦ 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) ¦ 1 x network - 10Base-T/100Base-TX/1000Base-TX - RJ-45 ¦ 1 x headphone/microphone combo jack - mini-phone stereo 3.5 mm |
| Miscellaneous | Miscellaneous |
| Cables Included | 1 x USB-C cable - external - 27 cm ¦ 1 x USB-C cable - external - 1 m |
| Included Accessories | Club3D CAC-1903 power supply |
| Features | On/off switch for power adapter, 4K Ultra HD, DisplayPort Alt Mode |
| Compliant Standards | FCC, RoHS, EMI |
| Power | Power |
| Power Device | Power adapter |
| Voltage Required | AC 100 - 240 V |
| Power Provided | 100 Watt |
| System Requirements | System Requirements |
| OS Required | Apple MacOS X, Windows 10 |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 36.7 cm |
| Shipping Depth | 10.9 cm |
| Shipping Height | 7.9 cm |
| Shipping Weight | 239 g |
Χαρακτηριστικά
Product Code
04:364713
EAN Code
8719214471866
Manufacturer
Club 3d
