CORSAIR RMx Series RM650x / Power supply (internal) / ATX12V / EPS12V / 80 PLUS Gold / AC 100-240 V / 650 Watt / Europe | CP-9020198-EU
Product Specification
| Device Type | Power supply - internal |
| Specification Compliance | ATX12V / EPS12V |
| PSU Form Factor | ATX |
| Localisation | Europe |
| Input Voltage | AC 100-240 V |
| Frequency Required | 47 - 63 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 4 x 4 PIN internal power ¦ 7 x 15 pin Serial ATA power ¦ 4 x 8 pin PCI Express power with detachable 2 pin section |
| Power Capacity | 650 Watt |
| Output Current | +3.3V - 20 A ¦ +5V - 20 A ¦ +12V - 45.8 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A |
| Modular Cable Management | Yes |
| 80 PLUS Certification | 80 PLUS Gold |
| Included Accessories | Cable ties |
| Cooling System | 135 mm fan |
| Features | Overheat protection, over current protection, over voltage protection, short-circuit protection, DC-DC technology, Zero RPM fan mode, fully modular, LLC resonant converter technology, magnetic levitation bearing cooling fan |
| Service & Support | Limited warranty - 10 years |
| Width | 15 cm |
| Depth | 16 cm |
| Height | 8.6 cm |
Features - Corsair - CP-9020198-EU
More Details
Product Code
03:159382
EAN Code
0840006605072
Manufacturer
Corsair
