Corsair Vengeance Series 550M / Power supply / ATX12V 2.4/ EPS12V 2.92 / 80 PLUS Bronze / AC 100-240 V / 550 Watt / matte black | CP-9020111-DE
Corsair Vengeance Series 550M / Power supply / ATX12V 2.4/ EPS12V 2.92 / 80 PLUS Bronze / AC 100-240 V / 550 Watt / matte black | CP-9020111-DE
Description Vengeance Series power supply units are an excellent choice for basic system builds and desktop PC computer upgrades. Corsair Vengeance Series 550M / Power supply (internal) / 80PLUS Bronze / 550Watt / matte black | CP-9020111-DESpecial Features
Product features
|
Product Specification
Device Type | Power supply - internal |
Specification Compliance | ATX12V 2.4/ EPS12V 2.92 |
PSU Form Factor | ATX |
Colour | Matte black |
Localisation | Germany |
Input Voltage | AC 100-240 V |
Frequency Required | 47 - 63 Hz |
Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 4 x 4 PIN internal power ¦ 5 x 15 pin Serial ATA power ¦ 1 x 4 PIN mini-power connector |
Output Voltage | +3.3, +5, ±12 V |
Power Capacity | 550 Watt |
Output Current | +3.3V - 25 A ¦ +5V - 20 A ¦ +12V1 - 25 A ¦ +12V2 - 25 A ¦ +12V3 - 25 A ¦ -12V - 0.8 A ¦ +5VSB - 3 A |
Modular Cable Management | Yes |
80 PLUS Certification | 80 PLUS Bronze |
MTBF | 100,000 hours |
Features | Sleeved cables, overheat protection, over current protection, over voltage protection, overpower protection, short-circuit protection, triple 12V rails, semi-modular |
Compliant Standards | UL, TUV, BSMI, cUL, CB, CCC, FCC, RoHS, WEEE, ICES, KC, EAC, China RoHS, RCM |
Service & Support | Limited warranty - 5 years |
Width | 15 cm |
Depth | 14 cm |
Height | 8.6 cm |
Weight | 1.57 kg |
