D-Link DAP-3711 / Wireless bridge / Wi-Fi 5 / 5 GHz / DC 24 V (PoE) | DAP-3711
Product Features
- TDMA technology cuts through the chatter, creating even stabler coverage
The DAP-3711 transmission capability is augmented thanks to its integrated Time Division Multiple Access (TDMA). Everything works more efficiently on a schedule, and the DAP-3711 is no different: TDMA creates a schedule for multiple connected clients to work to. Senders and receivers get their own time slot for transmissions. This eliminates hidden node data collisions, in turn maximizing airtime efficiency, significantly cutting down interference and making for a highly scalable solution. - Form without sacrificing function
It can be hard to look good while still being functional. Yet the DAP-3711 strikes the balance just right. The smooth case in crisp white makes for a low-key form that can effortlessly fit any outdoor setting without drawing attention. Being as functional as it is well-formed, it champions an IP66 rating, fighting dust and repelling water, all while maintaining its unassuming looks. - Cutting edge hardware makes the previously impossible, possible
The DAP-3711 features state-of-the-art hardware, including a high-gain 15 dBi directional antennas. This powerful antenna effortlessly extends high-speed coverage to distances of up to 5 km away. - Discreet deployment that's hassle-free with Power Over Ethernet (PoE)
Power sockets can be tricky to come by, especially in outdoor deployments. But PoE makes for easy installation and a simple, clean setup. No need to run extra power lines, no added hassle when configuring your hardwiring, and no more cable clutter.
Special Features
- Features high-gain 15 dBi directional antenna supplying high-speed, stable coverage to up to 5 km away
- Integrated TDMA Technology cuts through interference to ensure high-speed, consistent coverage
- Superior throughput with single-band transfer speeds of up to 867 Mbps
- Refined design effortlessly blends into any setting
- Supports WPA2 - Wi-Fi security for more protection
- Support for Power over Ethernet means less wires, for cleaner and easier deployment
- Features an IP66 rating, boasting water-resistant and dust-tight housings
Product Specification
Device Type | Wireless bridge |
Width | 8.8 cm |
Depth | 4.5 cm |
Height | 28.8 cm |
Weight | 600 g |
Networking | Networking |
Form Factor | External |
Connectivity Technology | Wireless |
Data Transfer Rate | 867 Mbps |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Network / Transport Protocol | NTP, DHCP |
Routing Protocol | Static IP routing |
Remote Management Protocol | NTP, DHCP |
Frequency Band | 5 GHz |
Max Range Open Space | 5 km |
Performance | Bandwidth: 20 MHz Bandwidth: 40 Mhz Bandwidth: 80 MHz |
Status Indicators | Power, signal strength, WLAN, LAN |
Features | VLAN support, Syslog support, MAC address filtering, firmware upgradable, Auto Channel Select (ACS), reset button, Time Division Multiple Access (TDMA), WDS access point, dustproof, waterproof, 8KV surge protection |
Encryption Algorithm | WPA2, 128-bit AES |
Authentication Method | Radio Service Set ID (SSID) |
Compliant Standards | IEEE 802.11i |
Aerial | Aerial |
Antenna | Internal |
Directivity | Directional |
Gain Level | 15 dBi |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | 1 x 1000Base-T - RJ-45 1 x 1000Base-T (PoE) - RJ-45 |
Miscellaneous | Miscellaneous |
Compliant Standards | FCC, IP66 |
Power | Power |
Power Over Ethernet (PoE) Supported | PoE |
Power Device | Power injector |
Voltage Required | DC 24 V (PoE) |
Power Consumption Operational | 15 Watt |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | -40 °C |
Max Operating Temperature | 65 °C |
Humidity Range Operating | 0 - 90% |
