Datalogic Gryphon I GD4590-HC / BPOC Kit / barcode scanner / handheld / 2D imager / decoded / keyboard wedge, RS-232, USB | GD4590-HCK10-BPOC
Description
The Gryphon I imager stands out with an elegant and trendy design, unchallenged ergonomics and features an advanced sensor with 2D technology for outstanding performance.
Datalogic Gryphon I GD4590-HC / BPOC Kit | GD4590-HCK10-BPOC
Special Features
- Superior scanning and depth of field
- Multi-interface options
Product Specification
| Type | Barcode scanner - handheld |
| Colour | Black |
| Interface Type | Keyboard wedge, RS-232, USB |
| Scan Element Type | 2D imager |
| Sensor Resolution | 1280 x 800 |
| Light Source Wave Length | 650 nm |
| Skew (Degrees) | 65 |
| Pitch (Degrees) | 65 |
| Print Contrast Signal (PCS) | 15% |
| Decode Capability | MaxiCode, Aztec code, MicroPDF417, Postnet, PDF417, Data Matrix, PLANET, Australian Post, British Post, China Post, Japanese Post, Kix (Netherlands) Post, MacroPDF417, RM4SCC, Royal Mail, Micro QR code, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, GS1 DataBar Composites, GS1 DataBar Stacked, China Han Xin Code, UPC A Composite, UPC E Composite |
| TTL Decoding | Decoded |
| Connectivity Technology | Wired |
| OK Notification | Beeper, LED indicator |
| Features | Datalogic Three Green Lights (3GL), Green Spot technology, Digimarc Barcode Technology, Direct Part Mark (DPM) |
| Interfaces | 1 x USB ¦ 1 x keyboard wedge ¦ 1 x RS-232 |
| Cables Included | 1 x USB cable |
| Compliant Standards | RoHS, IP52 |
| Width | 6.8 cm |
| Depth | 10.9 cm |
| Height | 16.6 cm |
| Weight | 161 g |
| Service & Support | Limited warranty - 5 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
Features - Datalogic - GD4590-HCK10-BPOC
More Details
Product Code
V384160
EAN Code
-
Manufacturer
Datalogic
