Digitus 24-Port Gigabit PoE Networkswitch,19 Zoll, L2 managed,2 Uplink Ports, SFP, 430 W, af/at / Managed / L2 / Gigabit Ethernet (10/100/1000) / 26 / 2 / 8000 entries / 52 Gbit/s / IEEE 802.3at / Power over Ethernet (PoE) / 1U | DN-95359

Product Features

· Provides 24 10/100/1000 Base-TX ports + 2 gigabit SFP ports
· Provides 24 PoE injector
· Build-in power supplies, 330W
· High back-plane bandwidth 52Gbps
· Support ICMPv6
· Support IPv6 Neighbour Discovery
· Support MLD Snooping
· Support IPv6 Telnet
· Support standard IP/ Extend IP / MAC IP / ARP ACL
· Support IGMP snooping for Multi-media application
· Support Port mirror and bandwidth control
· Support IEEE802.3x Flow control
· Support Port Based VLAN / 802.1Q Tag VLAN
· Support IEEE802.3ad Port trunk with LACP
· Support Spanning tree protocol IEEE802.1d/802.1w/802.1s
· Support IEEE 802.1p class of service
· Support IEEE 802.1x user authentication
· Support Broadcast storm filter
· Support System event log
· Support command line interface management
· Management by Web / SNMP / SSH / Telnet (IPv6 ready) / Console
· Switching Capacity: 52 Gbps
· Forwarding Capacity: 38.7 Mpps
· Forwarding Mode:Store and Forward
· Packet Buffer Memory: 4.1 Mbit
· RAM for CPU: 1 Gbit
· Flash Memory: 128 Mbit
· MAC Address Table: 8K
· Max. Jumbo Frame size: 16K
· VLAN Quantity: 4K
· ACL Table: 512
· L3 Interface: 32
· Port Queues: 8
· Dimensions: 440 x 200 x 44 mm
· Operating Temperature: 0 to 40
· Storage Temperature:-10 to 70
· Operating Humidity: 5 to 95% Noncondensing
· Power Method: 100-240VAC, 50/60Hz
· Max. Power ConsumptionIncluding PoE Output: 330W
· Max. power consumption including PoE output: 330W

Special Fetures

· Provides 24 10/100/1000 Base-TX ports + 2 gigabit SFP ports, Provides 24 PoE injector
· Build-in power supplies, 330W, High back-plane bandwidth 52Gbps
· Support ICMPv6, IPv6 Neighbor Discovery,MLD Snooping, IPv6 Telnet, standard IP/ Extend IP / MAC IP / ARP ACL, IGMP snooping for Multi-media application
· Support Port mirror and bandwidth control,IEEE802.3x Flow control
· Support Port Based VLAN / 802.1Q Tag VLAN, IEEE802.3ad Port trunk with LACP
· Support Spanning tree protocol IEEE802.1d/802.1w/802.1s
· Support IEEE 802.1p class of service, IEEE 802.1x user authentication
· Support Broadcast storm filter, System event log, command line interface management
· Management by Web / SNMP / SSH / Telnet (IPv6 ready) / Console

Product Specification

Switch type	Managed
Switch layer	L2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	26
Installed SFP modules quantity	2
MAC address table	8000 entries
Switching capacity	52 Gbit/s
Networking standards	IEEE 802.3at
Power over Ethernet (PoE)	Yes
Rack mounting	Yes
Form factor	1U
