DIGITUS - Bulk cable - fibre optic - 50 / 125 micron - OM3 - halogen-free, outdoor - aqua | DK-35121/3-U

Product Features

· LSZH low smoke zero halogen
· UV-resistant
· Longitudinaly and laterally water-resistant
· Glass yarn armoured
· Non-metal rodent protection
· Metal free
· Core diameter : 50.0 ± 2.5 µm
· Cladding diameter : 124.8 ± 1.0 µm
· Core-non-circularity : 5.0 %
· Cladding-non-circularity : 1.0 %
· Core-cladding concentricity error : 1.0 µm
· Coating diameter : 245 ± 7 µm
· Coating non-circularity : 6.0 %
· Cladding-coating concentricity error : 12.0 µm
· OFL bandwidth : at 850mm : 1500 MHz x km ; at 1300mm : 500 MHz x km
· Effective modal bandwidth : at 850mm : 2000 MHz x km ; at 1300mm : 500 MHz x km
· Attenuation coefficient : at 850nm : 2.3 dB/km ; at 1300nm : 0.6 dB/km
· Fiber count (OM3) : 2-12 pc
· Max. number of loose tube : 1 pc
· Fiber number per tube : 2 - 12 pc
· Loose tube : 2.0 ± 0.2 mm
· Outer sheath material : LSZH ; CPR Dca, EN 50575: 2014+ A1: 2016
· Cable outer diameter : 6.5 ± 0.5 mm
· Max. allowable pulling force : 1400 N
· Crush resistance : 1000/200 N/100mm
· Temperature range : transport and storage : - 40°C to + 70°C ; installation : - 40°C to + 60°C ; operation : - 40°C to + 70°C

Special Fetures

· OM3 50/125µ
· Central loose tube 12 fibers
· Non-metallic rodent protection
· LSZH, CPR Dca

Product Specification

Network Cable Type	Bulk cable - OM3
Technology	Fibre optic
Type of Fibre Optics	Multimode
Jacket Material	Low Smoke Zero Halogen (LSZH)
Fibre Qty	12
Core / Cladding Diameter	50 / 125 micron
Features	Halogen-free, outdoor, flame retardant, UV resistant, water-resistant, colour coded fibres, metal free, rodent-resistant
Colour	Aqua
Manufacturer Warranty
Service & Support	15 years warranty
