Digitus DN-10-12U - Rack cabinet - wall mountable - grey, RAL 7035 - 12U - 10" | DN-10-12U
Please sign in so that we can notify you about a reply
Product Features
· Safety class rating IP20· Lockable safety-glass door
· 200° door opening angle
· 1-point-locking-mechanism on the front door
· 254 mm (10") profile rails mounted on the front side inside of the cabinet, galvanized
· 254 mm (10") profile rails are adjustable in depth
· 1.1 - 1.5 strong sheet steel with a high loading capacity, powder coated
· Cable entry with brush strip on the top and with plastic cover on the base
· Ventilation slots for active and passive ventilation and exhausting
· Equipment mounting depth max.: 240 mm
· Including grounding bolt on the bottom of the housing
Special Fetures
· Very compact enclosure· Easy to assemble in your office building
· Provides a neat cable management
Product Specification
| Product Type | Rack |
| Rack Type | Cabinet |
| Placing / Mounting | Wall mountable |
| Product Material | Steel |
| Rack Size | 10" |
| Height (Rack Units) | 12U |
| Width | 31.2 cm |
| Depth | 30 cm |
| Height | 59.2 cm |
| Inner Dimensions | 24 cm |
| Colour | Grey, RAL 7035 |
| Finish | Powder coat |
| Miscellaneous | |
| Weight Limit | 30 kg |
| Features | Lockable front door, glass door, adjustable rails, cable entry, 200° door opening |
| Compliant Standards | IP20 |
Features - Digitus - DN-10-12U
More Details
Product Code
03:166927
EAN Code
4016032474241
Manufacturer
Digitus
