DIGITUS DN-10160 / Network adapter / PCIe low profile / Gigabit SFP x 1 | DN-10160
Please sign in so that we can notify you about a reply
Product Features
· Supports Full/Half-duplex Auto-Negotiation, Auto-MDI/MDIX· Supports IEEE 802.1Q VLAN tagging
· Supports 1000 Mbps networks with automatic detection and setting
· Layer 2 functions: IEEE 802.3x Flow Control - IEEE 802.1Q VLAN
· SFP slot supporting the following transceivers: MiniGBiC 1000SX Multimode, 1000LX Singlemode, 1000BX Singlemode WDM
· Intel-Chipsatz - ensures a stable and efficient quality
· Integrated Heat Sink for stabilizing the SFP temperature
· Supports IPv4, IPv6 protocols
· Supports Jumbo Frames up to 9K
· Supports Windows 10, 8.1, 8, 7, Vista, XP, Mac OS X and Linux
· Operating temperature: 0°C - 55°C
· Weight: 40g
Special Features
· Use modern Fiber technology to connect your PC with the Network· Intel-Chipset - ensures a stable and efficient quality
· Integrated Heat Sink for stabilizing the SFP temperature
· Gigabit Ethernet Speed
· Compatible with most Gigabit SFP modules
· Includes low-profile / half-height installation bracket
Product Specification
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express x1 |
| Networking | Networking |
| Ports | Gigabit SFP x 1 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 1000Base-X |
| Data Link Protocol | Gigabit Ethernet |
| Features | Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), IPv6 support, half duplex mode, full duplex mode, Jumbo Frames support, IPv4 support, tagged VLAN |
| Compliant Standards | IEEE 802.1Q |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x 1000Base-X - SFP (mini-GBIC) |
| Software / System Requirements | Software / System Requirements |
| OS Required | Linux, Apple MacOS X, Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10 |
| Dimensions & Weight | Dimensions & Weight |
| Weight | 40 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 55 °C |
Features - Digitus - DN-10160
More Details
Product Code
03:165796
EAN Code
4016032392019
Manufacturer
Digitus
