DIGITUS DN-651127 / Switch / 8 x 10/100/1000 / DIN rail mountable / DC power | DN-651127

Product Features

· 8 x 10/100/1000 Base-TX Ethernet ports
· Automatic cable recognition - auto MDI/MDI-X function
· Supports standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
· LED display: Power (on/off), link (on/off/data)
· Store and forward technology for optimized data transfer
· Automatic speed and half/full duplex detection/adjustment
· Backplane capacity: 16 Gbps
· Forwarding capacity: 15 Mpps
· MAC address memory: 4K (auto-learning, auto-aging)
· Robust, flat metal case
· Excellent protection against short circuits
· Lightning and surge protection
· Suitable for DIN rail (top-hat rail) mounting
· Fanless design
· Electrostatic standard: Contact 8kV, air 12kV
· Power supply via terminal strip (3 clamps, +/-/PE)
· Power supply: DC 12 - 48 V
· Operating temperature: -40 °C to +80 °C
· Storage temperature: -40 °C to +80 °C
· Operating humidity: 5% - 95% (non condensing)
· Storage humidity: 5% - 95% (non condensing)
· Dimensions: L 121 x W 104 x H 29,5 mm
· Protection type: IP40
· Electricity consumption: <5 Watts

Special Features

· 8 x 10/100/1000 Base-TX Ethernet ports
· Suitable for DIN rail (top-hat rail) mounting
· Space-saving, flat housing
· Fanless design
· Store and forward technology for optimized data transfer
· Backplane capacity: 16 Gbps
· MAC address memory: 4K (auto-learning, auto-aging)
· Excellent protection against short circuits
· Lightning and surge protection

Product Specification

Device Type	Switch - 8 ports
Enclosure Type	DIN rail mountable
Subtype	Gigabit Ethernet
Ports	8 x 10/100/1000
Performance	Backplane switching capacity: 16 Gbps
MAC Address Table Size	4K entries
Features	Auto-uplink (auto MDI/MDI-X), fanless, metal housing
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Expansion / Connectivity	Expansion / Connectivity
Interfaces	8 x 1000Base-T RJ-45
Power	Power
Voltage Required	DC 12 - 48 V
Miscellaneous	Miscellaneous
Compliant Standards	IP40
Dimensions & Weight	Dimensions & Weight
Width	13.5 cm
Depth	16.2 cm
Height	5.3 cm
Environmental Parameters	Environmental Parameters
Min Operating Temperature	-40 °C
Max Operating Temperature	85 °C
Humidity Range Operating	5 - 95% (non-condensing)
Min Storage Temperature	-40 °C
Max Storage Temperature	85 °C
