DIGITUS DN-80115 / Switch / unmanaged / 16 x 10/100/1000 / rack-mountable | DN-80115
Please sign in so that we can notify you about a reply
Product Features
· 16x RJ45 ports· 10/100/1000Base-TX
· Network Standard IEEE 802.3x full-duplex flow control
· Compatible with other standards: IEEE802.3, IEEE 802.3u, IEEE 802.3ab
· Backplane bandwidth: 32 Gbps
· MAC addresses: 8K
· Forwarding rate: 1.488 Mpps per port
· LED indicator: Power, Link/Active
· Suitable for mounting in 10" enclosures, 1U
· Cooling: passive (fanless)
· Integrated power adaptor
· Input voltage: 100 240 V multivoltage, 50/60 Hz
· Power supply: 15 W
· Operation temperature: 0 °C 40°C
· Storage temperature: 0 °C 70 °C
· Relative humidity: 20% 85% (non-condensing)
Special Features
· High backplane bandwidth· Supports full-duplex flow control
· Meets the IEEE 802.3x network standard
· Integrated power adaptor
Product Specification
| Device Type | Switch - 16 ports - unmanaged |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 16 x 10/100/1000 |
| Performance | Backplane speed: 32 Gbps ¦ Forwarding rate: 1.488 Mpps |
| MAC Address Table Size | 8K entries |
| Features | Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), full duplex mode, fanless |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| Status Indicators | Power, link/activity |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 16 x 1000Base-T RJ-45 |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 15 Watt |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 24 cm |
| Shipping Depth | 6.7 cm |
| Shipping Height | 32 cm |
| Shipping Weight | 1.6 kg |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 20 - 85% (non-condensing) |
| Min Storage Temperature | 0 °C |
| Max Storage Temperature | 70 °C |
Features - Digitus - DN-80115
General
16-Port
More Details
Product Code
04:365827
EAN Code
4016032460237
Manufacturer
Digitus
