DIGITUS DN-80221-3 - Switch - Managed - 24 x 10/100/1000 + 2 x 10/100/1000/SFP (uplink) + 2 x SFP (mini-GBIC) (uplink) - desktop, rack-mountable | DN-80221-3
Please sign in so that we can notify you about a reply
Product Features
· 24 x RJ45 ports (1000Mbps)· 2 x RJ45/ SFP combo ports for fiber optic connection or Ethernet
· 2 x SFP uplink ports for SFP modules
· 1 x RJ45 console port
· Compatible with following standards: IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3z and 802.3ad - Auto MDI/MDI-X Funktion
· 8K MAC addresses
· QoS support layer 4 classification
· Port mirroring for efficient network surveillance
· Port Trunk for bandwidth aggregation
· VLAN for performance and security
· 802.1x Port Authentication
· SNMP Network Management
· Built-in Web-based management
· Surge protection +/- 6 kV
· Dimensions: 440 x 208 x 44 mm (WxDxH)
· Power Input Spec: AC:100-240V
· Power consmption: 6.28W
Special Fetures
· 24 x 10/100/1000BaseTX ports· 2 x Uplink RJ45/SFP combo ports
· 2 x SFP uplink ports
· 1 x RJ45 console port integrated
· Layer-2 features configurable via WebUI
· Extensive Layer 2 features for optimal configuration
· L2 features: VLAN, Link-Aggregation, Port-Mirroring, Port-Trunking, SNMP Netzwerk Management, QoS-/CoS-Anwendungen, STP/RSTP/MSTP
· Installation in 19" server and wall cabinets possible
Product Specification
| Device Type | Switch - 24 ports - Managed |
| Enclosure Type | Desktop, rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 + 2 x 10/100/1000/SFP (uplink) + 2 x SFP (mini-GBIC) (uplink) |
| Performance | Packet forwarding rate: 41.66 Mpps ¦ Switching capacity: 56 Gbps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | MSTP, RSTP, STP |
| Remote Management Protocol | SNMP |
| Features | Layer 2 switching, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, store and forward, Quality of Service (QoS), Class of Service (CoS), 802.1x authentication, 6KV Surge protection, Link Aggregation, layer 4 classification, port trunking |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1x |
| Status Indicators | Power, link/activity |
| Expansion / Connectivity | |
| Interfaces | 24 x 1000Base-T RJ-45 ¦ 2 x RJ-45/SFP uplink ¦ 2 x SFP uplink ¦ 1 x console RJ-45 |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| MTBF | 50,000 hours |
| Dimensions & Weight | |
| Width | 44 cm |
| Depth | 20.8 cm |
| Height | 4.4 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 56.2 cm |
| Shipping Depth | 30 cm |
| Shipping Height | 9 cm |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
Features - Digitus - DN-80221-3
General
24-Port
More Details
Product Code
04:357603
EAN Code
4016032467687
Manufacturer
Digitus
