DIGITUS DN-81002 / SFP (mini-GBIC) transceiver module / GigE / 1000Base-LX / LC single-mode / up to 80 km / 1550 nm | DN-81002
DIGITUS DN-81002 / SFP (mini-GBIC) transceiver module / GigE / 1000Base-LX / LC single-mode / up to 80 km / 1550 nm | DN-81002
€66.51 inc. VAT
DN-81002
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
· Mini GBIC SFP (Small Form Factor Pluggable) module· Compatible with the following manuafacturers: Allied Telesis, Allnet, Avaya, CISCO, D-Link, Edimax, FINISAR, FORCE 10, Gigamon Intellinet, KTI Networks, Level One, PLANET, Tenda, TP-Link, TRENDnet, Mikrotik , ENTERASYS, RIVERSTONE , Unifi, Ubiquiti, ZyXEL, ZTE
· High quality and excellent reliability
· 1.25 Gbps Maximum Data Rate
· Compliant to IEEE 802.3z Gigabit Standard
· Class 1 laser product compliant with EN 60825-1
· Easy plug-and-play installation
· MSA (Multi Source Agreement) compliant
· Hot pluggable
· Connector: 1x LC Duplex
· 1000Base-ZX - For Long Haul
· Wavelength: 1550nm
· Transmission Power: Minimum 0 dBm, Maximum 5 dBm
· Sensitivity Receiving Power: Minimum -32 dBm
· For a Distance of up to 80km
· Suitable for 09/125µm Singlemode Fiber Cables
· Safe fast-locking mechanism
· 3.3V power supply
· Operating temperature: 0 °C ~ 70 °C
Special Features
· The Plug & Play fiber optic link enables quick installation· Sends data in high quality and additionally provides excellent reliability
· Distance up to 80km at a maximum data rate of 1.25Gbps
· Operating temperature: 0 °C ~ 70 °C
Product Specification
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-LX |
| Data Link Protocol | GigE |
| Data Transfer Rate | 1.25 Gbps |
| Optical Wave Length | 1550 nm |
| Max Transfer Distance | 80 km |
| Compliant Standards | IEEE 802.3z |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 1000Base-LX - LC single-mode x 2 |
| Compatible Slots | 1 x SFP (mini-GBIC) |
| Miscellaneous | Miscellaneous |
| Compliant Standards | Laser Class 1, EN 60825-1 |
Features - Digitus - DN-81002
More Details
Product Code
04:365833
EAN Code
4016032305675
Manufacturer
Digitus
