Product Features
· Mini GBIC SFP (Small Form Factor Pluggable) module· Compatible with the following manuafacturers: Allied Telesis, Allnet, Avaya, CISCO, D-Link, Edimax, FINISAR, FORCE 10, Gigamon Intellinet, KTI Networks, Level One, PLANET, Tenda, TP-Link, TRENDnet, Mikrotik , ENTERASYS, RIVERSTONE , Unifi, Ubiquiti, ZyXEL, ZTE
· Supports DDM (Digital Diagnostic Monitoring)
· High quality and excellent reliability
· 10 Gbps Maximum Data Rate
· Compliant to IEEE802.3ae 10 Gigabit Standard
· Class 1 laser product compliant with EN 60825-1
· Easy plug-and-play installation
· MSA (Multi Source Agreement) compliant
· Hot pluggable
· Connector: 1x LC Duplex
· Wavelength: 1310nm
· Transmission Power: Minimum -8 dBm, Maximum -0,5 dBm
· Sensitivity Receiving Power: Minimum -12.5 dBm
· For a distance of up to 10,0km
· Safe fast-locking mechanism
· Operating temperature: 0 °C ~ 70 °C
Special Features
· The Plug & Play fiber optic link enables quick installation· Sends data in high quality and additionally provides excellent reliability
· Distance up to 10km at a maximum data rate of 10Gbps
· Operating temperature: 0 °C ~ 70 °C
Product Specification
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Networking | Networking |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 GigE |
| Data Transfer Rate | 10 Gbps |
| Optical Wave Length | 1310 nm |
| Max Transfer Distance | 10 km |
| Features | Hot swap module replacement, Digital Diagnostics Monitoring Interface (DDMI) |
| Compliant Standards | IEEE 802.3ae |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x 10Gb Ethernet - LC female x 2 |
| Compatible Slots | 1 x SFP (mini-GBIC) |
| Miscellaneous | Miscellaneous |
| Compliant Standards | Plug and Play, Laser Class 1, EN 60825-1, MSA |
Features - Digitus - DN-81201
More Details
Product Code
03:166743
EAN Code
4016032324140
Manufacturer
Digitus
