DIGITUS DS-12880 - KVM / audio / USB switch - 4 x KVM port(s) - 1 local user - desktop | DS-12880

Product Features

· UHD resolution: 4K / 30 Hz (3840 x 2160p) / Subsampling: YUV 4:4:4
· Inputs: 4 x HDMI® inputs (2x1), 4 x USB B, 4 x audio combo socket 3.5 mm jack (microphone, speaker)
· Outputs (console): 1 x HDMI®, 2 x USB A (mouse, keyboard), 2 x Stereo Audio 3.5 m jack (microphone, speaker)
· Additional connection on the front side: 1 x USB A for additional peripheral equipment such as printers or USB sticks
· HDMI® version: 1.4b
· USB specifications: USB 2.0 compliant (full speed)
· Supports audio formats: Dolby True HD, DTS HD Master Audio
· Switching between the PCs: Switch on the front side or hot keys
· Status LED on front side shows current configuration
· The device is platform-independent, suitable for all operating systems
· Operating temperature: 0 °C ~ 50 °C
· Storage temperature: -20 °C to +60 °C
· Operating humidity: 0% - 80% RH (non-condensing)
· Case material: Metal
· Power supply: via USB or optional 9 V DC power adapter
· Dimensions: 20,2 x 11 x 4.4 cm (WxDxH)
· Weight: 780 g
· Power Spec: AC 100-240V
· Power Consmption: 2.7W
· DC plug Size: 5.5*2.1mm

Special Fetures

· Use one monitor, a mouse and keyboard to operate 4 computers with single display
· Supports a maximum UHD resolution of 4K / 30 Hz + FreeSync
· USB ports for mouse and keyboard
· Audio connections for microphone/speaker, supports Dolby True HD and DTS HD Master Audio
· Integrated USB hub with USB A port for additional peripheral equipment
· Switching between the PCs via switch on the KVM switch or hot key on the keyboard
· LED status and functional displays on the front side
· Laborious replugging of connection cables no longer necessary
· Real Plug and Play - no software or driver installation required (BIOS hardware connection)
· Sturdy metal housing

Product Specification

Device Type	KVM / audio / USB switch - 4 ports
Enclosure Type	Desktop
Subtype	KVM
Ports	4 x KVM port(s)
KVM Local Users Qty	1 local user
Keyboard / Mouse Interface	USB
Max Resolution	3840 x 2160 @ 30 Hz
Expansion / Connectivity
Interfaces	4 x keyboard (USB) / mouse (USB) Type B ¦ 2 x USB 2.0 Type A ¦ 4 x HDMI input ¦ 1 x HDMI output ¦ 4 x audio / microphone mini-jack ¦ 1 x audio output mini-jack ¦ 1 x microphone mini-jack
Miscellaneous
Compliant Standards	Plug and Play
Dimensions & Weight
Width	20.2 cm
Depth	11 cm
Height	4.4 cm
Weight	780 g
Environmental Parameters
Min Operating Temperature	0 °C
Max Operating Temperature	50 °C
Humidity Range Operating	0 - 80% (non-condensing)
