DIGITUS - Power distribution unit (rack-mountable) - AC 230 V - 3600 VA - 1-phase - input: power CEE 7/7 - output connectors: 12 (IEC 60320 C13 10A) - 1U - 19" - 2 m cord | DN-95426
DIGITUS - Power distribution unit (rack-mountable) - AC 230 V - 3600 VA - 1-phase - input: power CEE 7/7 - output connectors: 12 (IEC 60320 C13 10A) - 1U - 19" - 2 m cord | DN-95426
€55.3 inc. VAT
DN-95426
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
· Horizontal 19" installation in the rack· Housing: Aluminum profile
· Plastic components made of ABS UL-94V-0
· Input: Plug grounding contact CEE 7/7, 230 Vac / 16 A
· Output: Device socket 12 x IEC60320 C13, max. 10 A per output
· Cable: Cable cross section: 1.5 mm², length: 2 m
· Dimensions: 482.6 mm (19") x 45 (1U) x 45 mm (HxWxD)
Special Fetures
· Perfect current distribution for your network and IT rack· Compact construction, 19" 1U housing
· The jacks offer optimal space management and easy access
Product Specification
| Device Type | Power distribution unit - rack-mountable |
| Height (Rack Units) | 1U |
| Rack Size | 19" |
| Cord Length | 2 m |
| Power Device | |
| Input Voltage | AC 230 V |
| Input Wiring | 1-phase |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power CEE 7/7 |
| Power Output Connectors Details | 12 x power IEC 60320 C13 10A 10 A |
| Max Electric Current | 16 A |
| Power Capacity | 3600 VA |
| Miscellaneous | |
| Included Accessories | 2 mounting brackets |
| Cables Included | Power cable - integrated - 2 m |
| Features | Horizontal mount, aluminium profile |
| Compliant Standards | UL 94 V-0 |
| Dimensions & Weight | |
| Width | 4.5 cm |
| Depth | 4.5 cm |
| Height | 48.26 cm |
| Weight | 850 g |
Features - Digitus - DN-95426
More Details
Product Code
03:202444
EAN Code
4016032483472
Manufacturer
Digitus
