Product Features
· Safety class rating IP20· Lockable perforated steel front door
· 200° door opening angle
· 1-point-locking-mechanism on the front door
· 483 mm (19) profile rails mounted on the front- and rear side inside of the rack, galvanized
· 483 mm (19) profile rails are adjustable in depth
· Cable entry with brush strip on the top and with plastic cover on the base
· Roof is prepared for fan units (punched out entries)
· Ventilation slots for active and passive ventilation and exhausting
· Ventilation slots for active and passive ventilation and exhausting
· Equipment mounting depth min.-max.: 170-270 mm
Special Features
· Unmounted flat package delivery for cost- and space effciency· Optimized air ventilation and exhaustion
· Lockable perforated steel front door ensures safety
Product Specification
| Product Type | Cabinet |
| Placing / Mounting | Wall mountable |
| Product Material | Steel |
| Package Content | L-shaped rails |
| Rack Size | 19" |
| Height (Rack Units) | 12U |
| Width | 54 cm |
| Depth | 10 cm |
| Height | 59.5 cm |
| Weight | 15 kg |
| Shipping Dimensions (WxDxH) / Weight | 65 cm x 58 cm x 9 cm / 16 kg |
| Colour | Light grey, RAL 7035 |
| Finish | Powder coat |
| Miscellaneous | Miscellaneous |
| Features | Lockable front door, adjustable rails, top cable entry, single point locking system, with permanent frame, passive ventilation, 200° door opening |
| Compliant Standards | IP20, ANSI/SOHO |
Features - Digitus - DN-19-12U-S-PD
More Details
Product Code
04:331813
EAN Code
4016032432562
Manufacturer
Digitus
