DIGITUS Professional DS-72216 / KVM switch / 16 x KVM port(s) / rack-mountable | DS-72216
Please sign in so that we can notify you about a reply
Product Features
· Controlling several PCs via the 17" or 19" DIGITUS® modular console· The use of Cat.5 UTP cables allows a distance of 60 meters between the individual servers and the KVM switch
· Remote access via IP with the optional DS-51000-1 IP module
· Full control under all OS, in BIOS level, during boot, or at Blue Screens
· No software required
· Remote power wakeup on the target computer
· Extension via cascading possible
· Resolution independent of the installed console
· Hot plug support
· Keyboard and mouse emulation ensuring an error-free boot-up procedure of the computer
· Autoscan (5 to 90 sec., selectable)
· Compliant to USB 2.0 specification
Special Features
· Modular Cat.5 KVM switch for connecting up to 8 servers· Space-saving casing with 1U design height
· Suitable for modular KVM consoles DS-72210 and DS-72211
Product Specification
| Device Type | KVM switch - 8 ports - cascadable |
| Enclosure Type | Rack-mountable 1U |
| Subtype | KVM |
| Ports | 16 x KVM port(s) |
| Keyboard / Mouse Interface | USB |
| Compliant Standards | USB 2.0 |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 16 x KVM RJ-45 ¦ 2 x keyboard (USB) / mouse (USB) Type A |
| Expansion Slots | 1 Expansion Slot |
| Power | Power |
| Power Device | External power adapter |
| Miscellaneous | Miscellaneous |
| Included Accessories | 8 x Cat. 5 Dongle (VGA + USB) |
| Rack Mounting Kit | Included |
| Dimensions & Weight | Dimensions & Weight |
| Width | 44.5 cm |
| Depth | 14.8 cm |
| Height | 4.5 cm |
| Weight | 2.74 kg |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 0 - 80% (non-condensing) |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 60 °C |
Features - Digitus - DS-72216
More Details
Product Code
03:186989
EAN Code
4016032447634
Manufacturer
Digitus
