BIXOLON XT5-40N / Label printer / direct thermal / thermal transfer / Roll (11.4 cm) / 203 dpi / up to 356 mm/sec / USB, LAN, serial, USB host | XT5-40NS/BEG
Please sign in so that we can notify you about a reply
Special Features
- Aluminum body and special adhesiveless metal case
- Space-saving design with double folding door
- 3.5-inch full color or 4.3-inch full color touch LCD display
- Printing speed up to 14 ips (356 mm/sec)
- 203, 300 or 600 dpi resolution
- The industry's fastest Ethernet (1Gbit/sec) embedded
- Toolless maintenance of roller and print head
Product Specification
| Printer Type | Label printer - direct thermal / thermal transfer - monochrome |
| Printer | Printer |
| Print Speed | Up to 356 mm/sec - monochrome - 203 dpi |
| Built-in Devices | 4.3 inch LCD touch screen |
| Connectivity Technology | Wired |
| Interface | USB, LAN, serial, USB host |
| Max Resolution (B&W) | 203 dpi |
| Language Simulation | SLCS, BPL-Z, BPL-E, BPL-D |
| Features | Transmissive media sensor, reflective media sensor, ribbon end sensor, open head sensor |
| Fonts Included | 10 x bitmapped SLCS 1 x scalable SLCS 16 x bitmapped BPL-Z 1 x scalable BPL-Z 9 x bitmapped BPL-D 1 x scalable BPL-D 5 x bitmapped BPL-E |
| Barcodes | Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, QR code, MaxiCode, Aztec code, LOGMARS, UPC-A, UPC-E, MicroPDF417, Codabar, Code 128, Code 11, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, TLC39, GS1 DataBar-14, Plessey, Standard 2 of 5, EAN-8, EAN-13, MSI, UPC/EAN supplementals |
| Printer Features | Real time clock |
| RAM | RAM |
| RAM Installed (Max) | 512 MB |
| Technology / Form Factor | SDRAM |
| Flash Memory | Flash Memory |
| Flash Memory | 512 MB |
| Media Handling | Media Handling |
| Media Type | Labels, continuous forms, fanfold labels, black mark labels, notch, gap |
| Max Media Size | Roll (11.4 cm) |
| Min Media Size (Custom) | 25 mm |
| Max Media Size (Custom) | 114 mm |
| Media Sizes | Roll (11.4 cm), Roll (2.5 cm) |
| Max Printing Width | 104 mm |
| Max Printing Length | 4 m |
| Media Thickness Range | 0.06 mm - 0.3 mm |
| Roll Maximum Outer Diameter | 203 mm |
| Media Feeders | 1 x manual - Roll (11.4 cm) |
| Networking | Networking |
| Networking | Print server |
| Expansion / Connectivity | Expansion / Connectivity |
| Connections | 2 x USB host USB 1 x Gigabit LAN - RJ-45 Serial |
| Power | Power |
| Power Device | Power adapter - external |
| Voltage Required | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Software / System Requirements | Software / System Requirements |
| Software Included | Drivers & Utilities, Bartender UltraLite, OPOS/JavaPOS Drivers, CUPS Driver (Linux, MAC OS), Virtual COM software, Bixolon LabelArtist-II |
| OS Required | Apple MacOS, Linux, Microsoft Windows, Android, Apple iOS |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 5 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 80% RH |
| Dimensions & Weight | Dimensions & Weight |
| Width | 26.9 cm |
| Depth | 49 cm |
| Height | 32.4 cm |
| Weight | 13.98 kg |
Features - Bixolon - XT5-40NS/BEG
More Details
Product Code
CJ81446
EAN Code
8809794030499
Manufacturer
Bixolon
